Valet/Program Switch, 2-Pin BLUE Plug

The Valet/Program button should be accessible from the driver's seat. It plugs into the BLUE port

on the side of the unit. Consider how the button will be used before choosing a mounting location.

Check for rear clearance before drilling a 9/32-inch hole and mounting the button.

The BLACK three-pin port is provided for programming of the unit. When using the 998T

Bitwriter, it is possible to configure any and all of the programmable functions. For more infor-

mation please refer to the guide packaged with the programmer.

2002

Directed Electronics, Inc.
