System Features Learn Routine
The System Features Learn Routine dictates how the unit operates. Due to the number of steps,
they have been broken up into two menus. It is possible to access and change any of the feature
settings using the Valet/Program switch. However, this process can be greatly simplified by using the
998T Bitwriter. Any of the settings can be changed and then assigned to a particular transmitter, up
to four, a feature called Owner Recognition. Each time that particular transmitter is used to disarm
the system, the assigned feature settings will be recalled. Owner Recognition is only possible when
programming the unit via the 998T Bitwriter.
If the system was previously programmed using the 998T Bitwriter, the learn routine may be
locked. If the horn generates one long honk when attempting to program the unit, the learn routine
is locked and must be unlocked using the 998T Bitwriter before proceeding.
T T o o p p r r o o g g r r a a m m t t h h e e l l e e a a r r n n r r o o u u t t i i n n e e : :
1.
2.
3.
4.
©
2002
Directed Electronics, Inc.
K K e e y y . . Turn the ignition on and then back off. (The heavy-guage PINK
wire of the relay satellite must be connected.)
S S e e l l e e c c t t M M e e n n u u . . Press and hold the Valet®/Program switch until either the
LED flashes once and the horn honks once to select Menu One, or the
LED flashes twice and the horn honks twice to select Menu Two.
C C h h o o o o s s e e . . Within 10 seconds, press and release the Valet®/Program switch
the number of times corresponding to the feature number you want to
program. (See Feature Menus.) Once the Valet®/Program switch has
been pressed and released the desired number of times, press it once more
and hold it. After a second, the LED will flash to indicate which feature
you have accessed. For example, in Menu Two, groups of eight flashes
would indicate access to the status output feature (Feature 2-8). The horn
will also honk eight times (if connected).
T T r r a a n n s s m m i i t t . . The transmitter is used to select the desired setting. As shipped,
the unit is configured to the LED ON settings. These are the default
settings. Pressing the lock button will set it to the LED ON setting. The
LED will light solid (stop flashing) to indicate the setting. The horn will
honk once (if connected). Pressing the unlock button will change the
setting to the LED OFF setting. The LED will go out indicating the
change and the horn will honk twice (if connected).
21
