Under Unit Features - Digi TransPort WR44v2 Installation Manual

2.4 Under Unit Features

TransPort WR44
1
TransPort WR44 R
1. Unit mounting holes.
2. SIM slot cover plate mounting hole.
3. Reset button - The reset button allows the user to return the unit to its factory default settings. It is recessed
[to avoid accidental reset], and can be accessed via a small 2.5mm hole located on the underside of the
unit.
2.4.1 Reset instructions
Step 1) Turn the unit on and wait 15 seconds for the unit to complete its initialization process.
Step 2) Press and hold the reset button gently for 5 seconds. After this time, the unit will automatically
re-boot and display a pattern of alternating LEDs flashing followed by the normal boot sequence.
Note: Do not remove power from the unit during this operation as corruption of the flash memory may occur.
TransPort ® WR44v2 Installation Guide
[Front of Unit]
3
[Rear of Unit]
[Front of Unit]
3
[Rear of Unit]
Page 11
2
1
