- Page 1 4000 Series Routers Wireless GSM/GPRS/EDGE/UMTS/HSDPA/HSUPA Installation Guide...
- Page 2 Digi International reserves the right to modify or revise all or part of this document, its contents, and any products described herein at any time without prior notification and shall not be responsible for any loss, cost or damage, including consequential damage, caused by reliance on these materials.
- Page 3 Any attempt to service or repair the unit by the user will void the product warranty. The MR4110, ER4110 and HR4110 are designed for indoor use only and should be used in an environment that is suitable for computers and other electronic equipment.
- Page 4 However, GSM based products contain radio devices which require specific consideration. Please take the time to read and understand the following guidance. Digi International assumes no liability for an end user‟s failure to comply with these precautions.
- Page 5 MR4110/ER4110/HR4110 Installation Guide Preface This guide describes the installation procedure for the MR4110, ER4110 and HR4110. It is intended to provide sufficient information for you to be able to connect the unit to your terminal equipment and power supply. A complete reference guide to the software features that are available on the product is available separately in PDF format that can be downloaded from the Digi International website (www.digi.com).
- Page 6 MR4110/ER4110/HR4110 Installation Guide Package Contents When you receive the router carefully unpack it and check the contents. These should include: MR4110, ER4110 or HR4110 system unit (one of the following models): 81-MR4110-SSEU-00 81-MR4110-SSEU-01 (includes GPS option) 81-ER4110-SSEU-00 81-ER4110-SSEU-01 (includes GPS option)
-
Page 7: Front Panel Features
MR4110/ER4110/HR4110 Installation Guide 1 Introduction The MR4110, ER4110 and HR4110 are compact IP routers that facilitate the transmission of data over wireless GSM or 3G networks. The data rates and network types supported depend on the model type. GPRS (General Packet Radio System) is an IP-based data transmission service that runs over GSM wireless networks. - Page 8 Illuminates steady when there is a network connection to the LAN port and flashes when data is transmitted or received. 3G/GSM On the MR4110 and ER4110, this indicator is connected directly to the GSM module within the router and operates as described in the GSM Status Indicator Functions table below.
- Page 9 MR4110/ER4110/HR4110 Installation Guide 3G Status Indicator Functions No connection to any network type. 1 blink Connected to GPRS network. 2 blinks Connected to EDGE network. 3 blinks Connected to UMTS network. 4 blinks Connected to HSDPA/HSUPA network. GSM Status Indicator Functions GSM module is in SLEEP or Charge-only mode.
- Page 10 STP cable. EXP. The socket labelled EXP. may be used to connect various accessories supplied by Digi International. For further information please contact your supplier. Reset switch This is located on the underside of the unit near the front. Pressing the switch gently with...
-
Page 11: Installation
Digi International can supply a range of suitable aerials. Important Note If you are going to be using the Sar/OS Connection Wizard to configure the unit‟s Ethernet... - Page 12 MR4110/ER4110/HR4110 Installation Guide Step 2 – Fitting the wireless antenna The router is supplied with a “stub” antenna suitable for with the model you have ordered. Alternatively you may have ordered a different type of antenna separately. In either case this should be screwed onto the SMA aerial connector on the rear of the unit.
- Page 13 Step 1 – Install the Connection Wizard Download the connection wizard from the Digi website and install the software on your Step 2 – Run the Wizard Once the wizard has been installed on your PC, run it from the Windows Start menu.
-
Page 14: General Specifications
MR4110/ER4110/HR4110 Installation Guide 4 General Specifications Model numbers 81-MR4110-SSEU-00 81-MR4110-SSEU-01 (MR4110 with GPS) 81-ER4110-SSEU-00 81-ER4110-SSEU-01 (ER4110 with GPS) 81-HR4110-SSEU-00 81-HR4110-SSEU-01 (HR4110 with GPS) Power supply 12V DC / 1.5A Dimensions W160 x D120 x H32 mm Weight 0.53Kg Operating temp. range... - Page 15 MR4110/ER4110/HR4110 Installation Guide GPS (optional) Fastrax iTrax03-02: 12-channel, -153 dBm tracking sensitivity...
-
Page 16: Declaration Of Conformity
ENGLAND declare under our sole responsibility that the following product(s): Models: MR4110, ER4110, HR4110 Part numbers: 81-MR4110-SSEU-00 81-MR4110-SSEU-01 (MR4110 with GPS) 81-ER4110-SSEU-00 81-ER4110-SSEU-01 (ER4110 with GPS) 81-HR4110-SSEU-00 81-HR4110-SSEU-01 (HR4110 with GPS) 81-HR4110-SSEU-02 (HR4110 with HSUPA) conform(s) to the relevant harmonised standards: EN60950-1 A11: 2004 (Health &...
