Page 1: Installation Guide
T r a n s P o r t W R 4 4 v 2 ® Wireless Routers Installation Guide January 9, 2012 90001264_A... - Page 2 Digi International reserves the right to modify or revise all or part of this document, its contents, and any products described herein at any time without prior notification and shall not be responsible for any loss, cost or damage, including consequential damage, caused by reliance on these materials.
- Page 3 However, cellular-based products contain radio devices which require specific consideration. Please take the time to read and understand the following guidance. Digi International assumes no liability for an end user’s failure to comply with these precautions.
-
Page 4: Table Of Contents
TransPort ® WR44v2 Installation Guide Table of Contents 1 Package Contents ..............5 2 Introduction ................6 2.1 Enclosure Features ..................7 2.2 Front Panel Features ..................8 2.3 Rear Panel Features ..................9 2.4 Under Unit Features ..................10 2.5 Additional Hardware Features ................11 3 Installation .................13 4 Configuration ................15 4.1 Network Settings .....................15 4.2 Web Interface ....................15... -
Page 5: Package Contents
TransPort ® WR44v2 Installation Guide 1 Package Contents TransPort WR44 v2 Wireless Routers Installation Guide TransPort WR44 Installation Guide Telemetry Connector [Telemetry models only] Ethernet Cable PSTN Cable [PSTN & DialServ models only] Cellular Antenna(s) Power Supply Adapters [Non-US models only] Power Supply (some models may include a DC Power Cord or have no Power Supply) -
Page 6: Introduction
Digi TransPort WR routers are ideal for transportation and mobile applications. Flexible power options include AC, DC and 4-pin Molex connectors for direct integration into vehicle applications. Also available is the Digi Remote Manager™ which provides easy setup, configuration and maintenance of large installations of Digi TransPort devices. -
Page 7: Enclosure Features
TransPort ® WR44v2 Installation Guide 2.1 Enclosure Features TransPort WR44 TransPort WR44 R TransPort WR44 DSL Variant 1. Commercial Enclosure 2. Mounting Feet 3. Rugged Enclosure 4. Mounting Tabs Page 7... -
Page 8: Front Panel Features
TransPort ® WR44v2 Installation Guide 2.2 Front Panel Features TransPort WR44 DSL Variant 1. USB Host Connector - The USB host connector may be used to connect compatible USB 2.0 client devices such as memory sticks, and serial adapters. The total current available to power USB devices is 0.5A. - Page 9 TransPort ® WR44v2 Installation Guide • Constant red - no DSL is detected. • Flashing red - DSL is detected and unit is trying to train up to the DSL signal. • Constant green - DSL is active. • Flashing green - Data is being transferred LED Status Indicator - LINK - Illuminates steady when a wireless data connection has been established.
-
Page 10: Rear Panel Features
TransPort ® WR44v2 Installation Guide 2.3 Rear Panel Features WWAN PRIMARY WIFI SECONDARY WWAN SECONDARY WIFI PRIMARY 9-36VDC 3.5A MAX MAIN LAN2 LAN1 LAN0 AUX. LAN3 SERIAL 0 1. Primary Cellular (WWAN) Antenna Connector - This SMA female connector is used to connect the unit’s primary cellular antenna. -
Page 11: Under Unit Features
TransPort ® WR44v2 Installation Guide 2.4 Under Unit Features TransPort WR44 [Front of Unit] [Rear of Unit] TransPort WR44 R [Front of Unit] [Rear of Unit] 1. Unit mounting holes. 2. SIM slot cover plate mounting hole. 3. Reset button - The reset button allows the user to return the unit to its factory default settings. It is recessed [to avoid accidental reset], and can be accessed via a small 2.5mm hole located on the underside of the unit. -
Page 12: Additional Hardware Features
TransPort ® WR44v2 Installation Guide 2.5 Additional Hardware Features The TransPort WR44 v2 is available with various hardware options, as shown below: WWAN PRIMARY WIFI SECONDARY WWAN SECONDARY WIFI PRIMARY 9-36VDC 3.5A MAX MAIN AUX. SERIAL 0 LAN3 LAN2 LAN1 LAN0 SERIAL 1 SERIAL 2... - Page 13 10. DialServ - This RJ11/FXS connection converts a PSTN analog modem to a RS-232 serial signal. For more information on the Telemetry 1, Telemetry 2, and the Fleet I/O Interfaces please see the product specific user’s guides which can be found at: http://ftp1.digi.com/support/documentation/transport/technicalnotes.htm Page 13...
-
Page 14: Installation
TransPort ® WR44v2 Installation Guide 3 Installation Mounting Tips The TransPort WR44 should be positioned on a flat, level surface or via a wall-mount, rackmount, or DIN rail mounting brackets (see the Accessories section on page 23 for all options). The unit is designed for indoor use (except for the WR44 R) and should be mounted in a location with adequate ventilation. - Page 15 By default, SIM 1 is used for access to the primary network and SIM 2 is used for the back-up network. For added security, Digi offers a “SIM Slot Cover Plate” that can be installed on the unit to deter theft or tampering of the SIM cards, (see the Accessories section on page 23 for more information).
-
Page 16: Configuration
TransPort ® WR44v2 Installation Guide 4 Configuration Once the unit has been installed and powered up, it needs to be configured to communicate with the LAN and WAN. Configuration is performed either using the Command Line Interface (CLI) or the Web Interface. The Web Interface (accessed via a web browser e.g. - Page 17 TransPort ® WR44v2 Installation Guide The Quick Start Wizard is located in the Getting Started section on the Home menu. 4.2.1 Cellular: CDMA If your unit is to be used on a CDMA network, the embedded module must be provisioned on the network before it can make a connection.
- Page 18 Digi’s configuration file. As the mobile account information is stored on the CDMA module, performing a factory reset on the unit will not remove provisioning information from the CDMA module.
-
Page 19: Command Line Interface (Cli)
TransPort ® WR44v2 Installation Guide 4.3 Command Line Interface (CLI) In order to configure the unit serially, ensure that the unit is connected to a PC (as outlined in Step 5 on page 15 of the Installation section). Also, terminal emulation software (such as HyperTerminal) will be required. 4.3.1 CLI Notes •... - Page 20 (normally this router’s LAN IP address) DHCP 0 MASK x.x.x.x The subnet mask DHCP clients should use DHCP 0 DNS The DNS server DHCP clients should use For more information on CLI commands, visit http://www.digi.com/support/ and view the various reference manuals available. Page 20...
-
Page 21: Troubleshooting
“straight through” RS232 serial cable. This will allow you to change the configuration via the Command Line Interface (CLI). Please refer to the Digi TransPort User Guide for information on how to use the CLI. The User Guide can be downloaded from the Digi Support site. If you have further questions about your product please contact Digi Technical Support (see page 2 for contact information). -
Page 22: Specifications
Mobile Certifications - CDMA/ CDG TIA/EIA-690, CDG TIA/EIA-98-E EV-DO Wireless Carrier Certifications Certified by most major carriers. See www.digi.com for current listing. Safety UL 60950, CSA 22.2 No. 60950, EN60950 Emissions / Immunity CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55022 Class A... -
Page 23: Accessories
TransPort ® WR44v2 Installation Guide 7 Accessories AC Power Supplies North America (NA) 76000823 International (Intl.) 76000823 NA - Extended Temp. 76000790 Intl. - Extended Temp. 76000789 DC Power Cords Barrel Plug to Bare Wire 76000807 Barrel Plug to 12V Auto Power 76000810 Outlet 4-pin to 12V Auto Power Outlet... - Page 24 TransPort ® WR44v2 Installation Guide Antennas - Cellular Direct Mount, Quad Band, 2dBi 76002050 Direct Mount, Penta Band, 2dBi 76002052 Direct Mount, Dual Band, 3dBi DC-ANT-DBDP3 Magnet Mount, Penta Band, 2.5dBi 76002051 Magnet Mount, Dual Band, 4.0dBi DC-ANT-DBHG Glass Mount, Quad Band, 1.5dBi 76000844 Glass Mount, Penta Band, 0dBd 76000845...
-
Page 25: January
EN301489-7:v1.3.1 Safety: (article 3.1a) EN60950-1:2006 + A11:2009 Minnesota, USA, 4 January, 2012 (Place and date of issue) Authorised signature for and on behalf of Digi International Inc. Joel Young, VP, Engineering European Andreas Burghart Representative: Digi International GmbH Branch Breisach Kueferstr. - Page 26 This product contains high quality materials and components which can be recycled. At the end of its life this product MUST NOT be mixed with other commercial waste for disposal. Check with the terms and conditions of your supplier for disposal information. Digi International Ltd WEEE Registration number: WEE/HF1515VU Page 26...
- Page 27 © 2011 Digi International Inc. All rights reserved. Digi, Digi International, the Digi logo, a Digi International Company, the Digi web site, Digi Remote Manager, Digi TransPort, Digi TransPort WR, and Digi TransPort WR44 are trademarks or registered trademarks of Digi International, Inc.
