Page 1: Installation Guide
T r a n s P o r t W R 4 4 R R ® Wireless Routers Installation Guide 90001295_D September 3, 2013... -
Page 2: Product Disposal Instructions
Digi International reserves the right to modify or revise all or part of this document, its contents, and any products described herein at any time without prior notification and shall not be responsible for any loss, cost or damage, including consequential damage, caused by reliance on these materials. - Page 3 However, cellular-based products contain radio devices which require specific consideration. Please take the time to read and understand the following guidance. Digi International assumes no liability for an end user’s failure to comply with these precautions.
-
Page 4: Table Of Contents
TransPort ® WR44RR Installation Guide Table of Contents 1 Package Contents ���������������������������������������������������������������������������������������� 5 2 Introduction �������������������������������������������������������������������������������������������������� 6 2.1 Enclosure Features ........................7 2.2 Front Panel Features ......................... 8 2.3 Rear Panel Features ......................... 9 3 Installation �������������������������������������������������������������������������������������������������� 10 4 Configuration ���������������������������������������������������������������������������������������������� 12 4.1 Network Settings ........................ -
Page 5: Package Contents
TransPort ® WR44RR Installation Guide 1 Package Contents W R 4 4 R R O R T R A N S IG I TransPort WR44RR TransPort WR44RR Wireless Routers Installation Guide Power Supply Installation Guide Ethernet Cable SILICONE DIELECTRIC COMPOUND Dielectric Grease If any item is missing or damaged, please contact your supplier. -
Page 6: Introduction
Digi TransPort WR routers are ideal for transportation and mobile applications. Flexible power options include AC, DC and 4-pin Molex connectors for direct integration into vehicle applications. Also available is the Digi Remote Manager™ which provides easy setup, configuration and maintenance of large installations of Digi TransPort devices. -
Page 7: Enclosure Features
TransPort ® WR44RR Installation Guide 2�1 Enclosure Features TransPort WR44RR W R 4 4 R R O R T R A N S IG I 1. Rugged Enclosure 2. Mounting Tabs Page 7... -
Page 8: Front Panel Features
TransPort ® WR44RR Installation Guide 2�2 Front Panel Features 1. LED Status Indicator - POWER - Illuminates steady when power is connected. 2. LED Status Indicator - LAN (0, 1, 2, 3) - Illuminates steady when there is a network connection to the LAN port and flashes when data is transmitted or received. -
Page 9: Rear Panel Features
TransPort ® WR44RR Installation Guide 2�3 Rear Panel Features 1. Primary Cellular (WWAN) Antenna Connector - This TNC female connector is used to connect the unit’s primary cellular antenna. 2. Primary Wi-Fi (WLAN) Antenna Connector (Wi-Fi models only) - This TNC male connector is used to connect the unit’s secondary Wi-Fi antenna. -
Page 10: Installation
TransPort ® WR44RR Installation Guide 3 Installation Mounting Tips The TransPort WR44RR is designed for indoor and outdoor use. It should be mounted in a position to allow access for the cables on the rear panel. Front View W R 4 4 R R... - Page 11 By default, SIM 1 is used for access to the primary network and SIM 2 is used for the back-up network. The TransPort WR44RR has a SIM cover that should be fitted in place once the SIMs have been installed in order to meet the environmental specifications.
-
Page 12: Configuration
TransPort ® WR44RR Installation Guide 4 Configuration Once the unit has been installed and powered up, it needs to be configured to communicate with the LAN and WAN. Configuration is performed either using the Command Line Interface (CLI) or the Web Interface. The Web Interface (accessed via a web browser e.g. - Page 13 TransPort ® WR44RR Installation Guide • Mobile module and connection • Wi-Fi Access Point The Quick Start Wizard is located in the Getting Started section on the Home menu. 4.2.1 Cellular: CDMA If your unit is to be used on a CDMA network, the embedded module must be provisioned on the network before it can make a connection.
- Page 14 Digi’s configuration file. As the mobile account information is stored on the CDMA module, performing a factory reset on the unit will not remove provisioning information from the CDMA module.
- Page 15 Check with your carrier for information about the type of provisioning required and what, if any, data is required to be entered. For more information on configuring the unit, please refer to the Digi TransPort User Guide which is available at www.digi.com.
-
Page 16: Command Line Interface (Cli)
TransPort ® WR44RR Installation Guide 4�3 Command Line Interface (CLI) In order to configure the unit serially, ensure that the unit is connected to a PC (as outlined in Step 5 on page 11 of the Installation section). Also, terminal emulation software (such as HyperTerminal) will be required. 4.3.1 CLI Notes •... -
Page 17: Command Description
(normally this router’s LAN IP address) DHCP 0 MASK x�x�x�x The subnet mask DHCP clients should use DHCP 0 DNS The DNS server DHCP clients should use For more information on CLI commands, visit http://www.digi.com/support/ and view the various reference manuals available. Page 17... -
Page 18: Troubleshooting
“straight through” RS232 serial cable. This will allow you to change the configuration via the Command Line Interface (CLI). Please refer to the Digi TransPort User Guide for information on how to use the CLI. The User Guide can be downloaded from the Digi Support site. If you have further questions about your product please contact Digi Technical Support (see page 2 for contact information). -
Page 19: Specifications
Mobile Certifications - CDMA/ CDG TIA/EIA-690, CDG TIA/EIA-98-E EV-DO Wireless Carrier Certifications Certified by most major carriers. See www.digi.com for current listing. Safety UL 60950, CSA 22.2 No. 60950, EN60950 Emissions / Immunity CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55022 Class A... -
Page 20: Accessories
TransPort ® WR44RR Installation Guide 7 Accessories DC Power Cords CBL,Pwr,TransPort WR44RR, 4m 76000896 Antenna Pkg, X5 R Cellular (GSM)/GPS ANT 76000782 Antenna, WiFI, Thru-hole, TNC, 2.4/5GHZ, 10’ 76000877 WWAN TNC Antenna 76000888 Cables CBL,Serial,M12 to DB9,1m 76000897 CBL,Eth,M12,4-pin male to RJ45,2m... - Page 21 TransPort ® WR44RR Installation Guide Pin-out Diagrams The pin-out diagram for the 4-pin molded connector is shown below: PIN1 PIN 2 PIN 3 PIN 4 The pin-out diagram for the 8-pin molded connector is shown below: PIN 1 PIN 8 PIN 7 PIN 6 PIN 2...
-
Page 22: Connectors
TransPort ® WR44RR Installation Guide 8 Connectors Power Connecter M12 - 4 pin, A Coded Signal Power +ve GPIO 0 Power -ve GPIO 1 Serial Connector M12 - 5 pin, A Coded DB-9 (DCE) 2 (RXD) 3 (TXD) 8 (CTS) 7 (RTS) 5 (GND) Ethernet Connecter M12 - 4 pin, D Coded... -
Page 23: Certifications
TransPort ® WR44RR Installation Guide 9 Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 24 © 2013 Digi International Inc. All rights reserved. Digi, Digi International, the Digi logo, a Digi International Company, the Digi web site, Digi Remote Manager, Digi TransPort, Digi TransPort WR, and Digi TransPort WR44 are trademarks or registered trademarks of Digi International, Inc.
