Connect the Video Cable

• Connect one end of the video cable to the video connector on your PC and
the other end of the cable to the video connector on your monitor. Secure the
cable by turning the thumbscrews on each connector.

Connect the Serial or USB Touchscreen Cable

serial or USB cable
• Depending on your monitor, connect either the serial or USB touchscreen
cable. Connect one end to the appropriate port on the back of your computer.
Connect the other end of the cable to the touchscreen connector on your
touchmonitor. The touchscreen cable connectors should fit snugly into the
connectors on your touchmonitor and computer. Secure the cable by turning
the thumbscrews on each connector.
video cable
video cable
2-5
