Connector Information

Pin 1
Pin 2
Pin 3
After connecting the power cable to the monitor, but before applying power,
ensure that the power cable's black or brown wire connects to the monitor's
brown wire; the power cable's green wire connects to the monitor's green
wire; and the power cable's white or blue wire connects to the monitor's blue
wire.
B-22
E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
Mains line hot
monitor (brown)
Mains ground
monitor (green)
Mains line neutral
monitor (blue)
