Touchmonitor Controls

You can adjust the screen display by using the plastic knob labeled OSD located
on the right-hand side of the monitor.

Using the On Screen Display (OSD)

Push the OSD knob to access the OSD.
1
Turn the OSD knob to choose the item you want to adjust. The selected item
2
is highlighted. See figure 3.1 for OSD menu options.
3 Push the OSD knob to adjust the highlighted item.
The display unit automatically saves the new settings in about 45 seconds
after your last adjustments. The menu will automatically disappear or you
can push the OSD knob to make the menu disappear.
Figure 1.1
3-12
E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
R
OSD Menu
EXIT
OSD
RGB
