Multichannel Plug-ins Are designed for use on
stereo and multichannel tracks that require cor-
related processing, including stereo and multi-
channel limiting, compression, and similar ef-
fects.
Linking and Unlinking Controls on Multi-
Mono Plug-ins
When a multi-mono plug-in is used on a multi-
channel track of more than two channels, the
controls are normally linked. Adjusting the
Gain control on one channel, for example, will
adjust it for all channels.
If necessary, you can unlink plug-in controls on
specific channels of a track and edit them inde-
pendently. You can also selectively link the con-
trols of specific channels.
For example, to apply equal filter cutoffs to the
Ls and Rs (surround) channels in a 5.1 mix, you
could link enable just those channels in an un-
linked, multi-mono EQ plug-in. Adjusting the
controls in the plug-in window for either chan-
nel (Ls or Rs) adjusts the other, linked channel
as well.
Channel selector
Channel selector and Link controls
Channel Selector Accesses a specific channel
within a multichannel track for plug-in parame-
ter editing. This menu appears only on multi-
mono plug-ins inserted on tracks with more
than two channels.
Link Enable buttons
Master Link button
Chapter 32: Multichannel Tracks and Signal Routing (Pro Tools HD Only)
Master Link Button When enabled, links the
controls on all channels of a multi-mono plug-
in so that they can be adjusted in tandem.
Link Enable Buttons Let you selectively link the
controls of specific channels of a multi-mono
plug-in. Each square represents a speaker chan-
nel. The Master Link button must be disabled to
use the Link Enable buttons.
To unlink controls on a multi-mono plug-in:
Deselect the Master Link button. It is lit when
■
linked, unlit when unlinked.
To access controls for a specific channel:
Select the channel from the Channel selector.
■
To open a plug-in window for all channels of a
multi-mono plug-in:
Alt-click (Windows) or Option-click (Mac) the
■
Channel selector.
To link the controls of specific channels:
Deselect the Master Link button if it is not al-
1
ready deselected.
Click the Link Enable buttons for the chan-
2
nels whose controls you want to link.
For more information on using plug-ins, see
the DigiRack Plug-ins Guide .
