Alpine NVD-V001 SMART MAP PRO Owner's Manual
  1. Manuals
  2. Brands
  3. Alpine Manuals
  4. GPS
  5. NVD-V001 SMART MAP PRO
  6. Owner's manual
Alpine NVD-V001 SMART MAP PRO Owner's Manual

Alpine NVD-V001 SMART MAP PRO Owner's Manual

Digital information map prog. ver. 1.00
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
ALPINE ELECTRONICS, INC.
Tokyo office: 1-1-8 Nishi Gotanda,
Shinagawa-ku, Tokyo 141-8501, Japan
Tel.: (03) 3494-1101
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
1-888-NAV-HELP (1-888-628-4357)
ALPINE ELECTRONICS OF CANADA, INC.
Suite 203, 7300 Warden Ave. Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
1-888-NAV-HELP (1-888-628-4357)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Tel.: (03) 9769-0000
ALPINE ELECTRONICS GmbH
Kreuzerkamp 7-11
40878 Ratingen, Germany
ALPINE ITALIA S.p.A.
Via C. Colombo 8, 20090 Trezzano Sul
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue De La Belle Etoile, Z.I. Paris Nord Il
B.P. 50016 F-95945, Roissy,
Charles De Gaulle Cedex, France
Tel.: 01-48 63 89 89
ALPINE ELECTRONICS OF U.K., LTD.
13 Tanners Drive, Blakelands,
Milton Keynes MK14 5BU, U.K.
Tel.: 01908-61 15 56
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava)-Apdo. 133, Spain
Yamagata Printing
Tel.: 34-45-283588
Co., Ltd.
2-6-34, Takashima,
Designed by ALPINE Japan
Printed in Japan (Y)
Nishi-ku, Yokohama,
Kanagawa, Japan
Tel.: 02102-45 50
Naviglio MI, Italy
Tel.: 02-48 47 81
68P30540Y44-O
SMART MAP PRO
NVD-V001
OWNER'S MANUAL
Please read before using this disc.
MODE D'EMPLOI
Veuillez lire avant d'utiliser ce disque.
MANUAL DE OPERACIÓN
Lea este manual antes de utilizar este disco
DIGITAL INFORMATION MAP
CARTE ROUTIERE SUR DVD ROM
MAPA DE INFORMACIÓN DIGITAL
Prog. Ver. 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVD-V001 SMART MAP PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpine NVD-V001 SMART MAP PRO

Summary of Contents for Alpine NVD-V001 SMART MAP PRO

  • Page 1 Ontario L3R 9Z6, Canada MANUAL DE OPERACIÓN Tel.: 1-800-ALPINE-1 (1-800-257-4631) 1-888-NAV-HELP (1-888-628-4357) Lea este manual antes de utilizar este disco ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, Victoria 3173, Australia Tel.: (03) 9769-0000 ALPINE ELECTRONICS GmbH Kreuzerkamp 7-11 40878 Ratingen, Germany Tel.: 02102-45 50...
  • Page 2 Precautions PRECAUTIONS IMPORTANT INFORMATION, L L L L L Do not use the navigation system to route you to emergency services. Not all PLEASE READ CAREFULLY locations of emergency service provid- BEFORE USING THIS PROD- ers such as police and fire stations, UCT.
  • Page 3 Alpine representative before using the position yourself. If this is the case, stop navigation system. the vehicle in a safe and legal manner and location before attempting opera- tion.
  • Page 4 They contain instructions on tant to fully understand the mean- how to use the system in a safe and ings of these pictorial displays in effective manner. Alpine cannot be order to use this manual and the responsible for problems resulting system properly.
  • Page 5 Failure to do or knowledge of safe driving practice. so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Serv- USE THIS PRODUCT FOR ice Centre for repairing. MOBILE 12V APPLICATIONS.

  • Page 6: Precautions

    The Disk and Database are not to be used for commercial purposes. • Neither Aisin AW, Alpine nor NavTech guarantees to the customer that the func- tions included in the Disk and Database meet a specific objective of user.

  • Page 7: Table Of Contents

    54 ....Category Icons on Map 52 ......In case of difficulty • This manual explains operation assuming that Alpine NVE-N077P and RUE-4131 are used. If other model(s) are used, some display screens may vary and locations of the buttons on the remote control are different (see "Buttons and functions of remote control"...

  • Page 8: Preface

    Preface Navigation terminology Navigation Waypoints The navigation system displays and tracks the You specify points you wish vehicle's position and movement on a moving map to pass by along the way to display. When a destination is input, the navigation your destination and they are system quickly calculates a route and guides you indicated with the waypoint...

  • Page 9: Features

    Features • Automatic Route Calculation • Traffic-Circle Turn Guidance Just select the destination and your naviga- At a traffic circle, the system guides you tion system does the rest, automatically where to turn by indicating the road number searching for the route you need. When starting with the entered road.

  • Page 10: Before Using The System

    Before Using The System Before Using The System If the language has not been Rewriting operating selected yet (when the system is used for the first time), the guide system programme language selection menu is displayed. Select (highlight) the desired guide language by tilting If a different version of the map disc has been the joystick.

  • Page 11: Map Displays

    How to switch the displays. You can manually select the desired guidance displays for your convenience. map displays The Basic Guidance Display is automatically displayed when travelling starts. Pressing the Once the route setting has been performed and button on the remote control while the Basic travelling started, the navigation system pro- Guidance Display is being displayed switches vides the driver all of the major route informa-...

  • Page 12: Switching The Display On/Off

    ENTER button. on/off The map screen is displayed. With the Alpine navigation system, when the ignition key is turned to ACC or ON and the display monitor is set in the navigation display mode or external input display mode, the opening screen will be automatically displayed.

  • Page 13: Setting The Language Mode

    The important message saying Setting the language "Please be sure to read this!" is displayed. After you have read this mode important message, press ENTER. The map screen is displayed. For the picture/voice guidance and texts, you can choose one of 6 languages as follows. •...

  • Page 14: Manual Backup

    Before Using The System The navigation system starts the Manual backup backup process and the display becomes darker for a little while. The display shows the opening The navigation system will automatically back screen, then "Please be sure to up (save) your new settings (for example, read this!"...

  • Page 15: Searching For Destinations

    Searching For Destinations Selecting Countries You can select your desired locations in the 15 countries. When you search for your destinations or points Some country areas include neighbour- of interest in other countries from their ad- ing countries as follows: dresses or categories, choose the desired FRANCE area: France (F), Andorra country first by following the procedure below.
  • Page 16 Searching For Destinations The city name selection menu is Searching for desti- displayed. There are 4 choices you can select. Select the desired nation from category menu item and press ENTER. (Easy mode) The city name of the last-4 If you know the category of the desired destina- search stored tion, you can easily display that destination by in memory.
  • Page 17 Repeat Step 5 above to complete a When 1 character is input, the the character inputtings of the city candidates for the next character name. are narrowed down (and the others disappear from the character These trian- pallet). gles indicate a You can also search for a location that there is a Tips...
  • Page 18 Searching For Destinations The system starts to calculate the During the calculation process, the route to the destination. display shows the details of the When the route search is started, destination and progress of the message "Motorway prefer- calculation process. ence calculation (or Ordinary road When the calculation has been preference calculation)"...
  • Page 19 Searching for desti- City name nation from address (name of city/street) (Easy mode) The characters selected are displayed in the text window. If you know the address for the destination, you can display its location on the map by just inputting the address (name of the city/street).
  • Page 20 Searching For Destinations When the character inputtings of The Detailed Information screen the street name have been appears. Select "ADDRESS NUM- completed, select "LIST" at the top BER" from the menu and press of the character pallet and press ENTER. ENTER.
  • Page 21 Searching for desti- a The telephone number can be input using the numeric keypad on the nation from tel- remote control. For operation, see the Remote Control Reference Guide. ephone number. a When 1 numeral is input, the candidates for the next numeral are Tips (Easy mode) narrowed down (and the others...

  • Page 22: Searching For Destination From

    Searching For Locations Searching For Locations To search for the desired point of Searching for point of interest, follow Steps 3 to 9 of the "Searching for destination from interest from category" section (pages 16 to 18). category (Expert mode) If you know the category of the desired point of interest (P.O.I.), you can easily display that point of interest on the map by just selecting the...
  • Page 23 Searching for point of interest from address (Expert Mode) If you know the address of the desired point of interest (P.O.I.), you can easily display that point of interest on the map by just inputting the address. The display examples show when the Oxford Street is searched for.
  • Page 24 Searching For Locations The address number inputting pallet is displayed. Select the numerals for the address number and press ENTER. Range of Searchable Address Numbers Note: In the searchable range, there may be some address numbers that are not searchable. When the desired address number has been input, select "OK"...

  • Page 25: Telephone Number (Expert Mode)

    Searching for point of When the desired telephone number has been input, select interest from "OK" and press ENTER. telephone number (Expert mode) If you have stored the telephone number of the point of interest (P.O.I.) in memory, you can The details of the point of interest easily display that point of interest on the map appears in the display.
  • Page 26 Searching For Locations Moving the map to Searching for loca- search for locations tions by latitude/lon- gitude input The map can be freely moved with the joystick in 8 directions. The best way to find a location is first to display the wide range map and specify If you know the latitude and longitude of the the approx.

  • Page 27: Searching From Memory Points

    Searching from Searching from home/departure memory points point/waypoint/pre- If memory points have already been registered, vious destination you can call them out with a simple operation. For details on the registration method, see page If home/departure point/waypoint/previous Press the MENU button to display destination have already been registered, you the main menu.

  • Page 28: Searching From Local Points

    Searching For Locations Searching from local The reticule icon appears at the selected local point, then the point points menu appears. Select the desired name of point of interest and press ENTER. The system can display up to 5 points (max.) of Displays the interest in a range of 6 miles (10 km) around distance/direction...

  • Page 29: Storing Points Into Memory

    Storing Points Into Memory Registering your The confirmation message is displayed to ask you whether this home point will be registered as your home. If your home is not yet registered, select "YES" and press ENTER. First, you register your home. When your home is registered, setting the destination for return- The home ing home is simple.

  • Page 30: Storing Locations Into Memory

    Storing Points Into Memory The memory point editing list is Storing locations into displayed for 5 seconds as the registration completion message memory and the system switches to the map screen. • To return to the previous screen, press You can store up to 199 special points on the the RETURN button.

  • Page 31: Point Editing

    Point Editing Memory point editing - number/icon/ name/telephone number/position/ special usage Map Display The selected point is displayed on the map. You can change the memory point/telephone Deletion numbers, or add icons and names. The confirmation message for deletion is displayed. (See below.) Press the MENU button to display the main menu.
  • Page 32 Point Editing Number editing Icon Editing Select "ICON" and press ENTER. Select "No." and press ENTER. A list appears. Select the desired The icon list appears. Select the number and press ENTER. desired icon and press ENTER. The memory editing list with the The memory editing list is dis- number changed is displayed.
  • Page 33 Name Editing Telephone Number Editing Select "NAME" and press ENTER. Select "TEL. No." and press ENTER. The character pallet is displayed. The number pallet is displayed. Select the desired characters one Select the desired numeral and by one and press ENTER each press ENTER.
  • Page 34 Point Editing L Setting the point to avoid (POINT TO Memory Point Move AVOID) • This is set when there is a point that you do Select "POSITION" and press not want to be covered by route searches. ENTER. Routes are set to avoid roads between crossroads surrounding that point.

  • Page 35: Deciding The Route

    Deciding The Route Setting the destination When the search is complete, the required time and distance to the destination are displayed. When you have found the location you want to go to, the route search is carried out automatically. Find the destination on the map, then press ENTER.

  • Page 36: Setting Waypoints

    Deciding The Route Setting waypoints When the route search is complete, the current location is displayed. When you start driving this route, the guidance begins. You can set up to 5 waypoints from your current location to the destination. Set these points after the route searching from your current location to your destination has been completed.

  • Page 37: Searching For An Alternate Route

    Searching for an al- Immediately after a route search, you can search for an ternate route alternate route with the ROUTE button. 1. Immediately after a route The system can search for 3 different types of search, press the ROUTE routes: recommended routes, avoid routes, and button.

  • Page 38: Setting Route Options

    Deciding The Route Setting route options Confirming the searched route Press the MENU button to display the main menu. Select "Route" from the main menu, then select We recommend that before you begin driving "ROUTE PREF." and press ENTER. the route, you look at the entire route with the all-route display.
  • Page 39 Route editing This is for removing specific points from the guidance and changing the preference mode between points (motorway ↔ ordinary road), etc. The route editing screen is Press the MENU button to display displayed. the main menu. Select "Route" from the main Clears the present route menu, then select "ROUTE EDITING"...
  • Page 40 Deciding The Route Changing sequence of SHORT Select "SHORT" and press ENTER. waypoints for Today's Plan The sequence of the waypoints to go through can be automatically sorted in order of distance from the current vehicle position, or it can be manually changed in any order as you like.
  • Page 41 SORT Select "SORT" and press ENTER. First, select the destination you wish to go and press ENTER. Then, select the waypoints in the sequence as you like. The Today's Plan list with the new sequence is displayed. If the sequence displayed is acceptable, select "APPLY"...

  • Page 42: Drive Simulation

    Deciding The Route Drive simulation To end the drive simulation, press the RETURN button. After the "Demo finished." message, the navigation system returns automatically To check the searched route, you can carry out to the map screen. a drive simulation by selecting "Inform" from the main menu, then selecting "AUTO DRIVE."...

  • Page 43: Customizing (As You Like It)

    Customizing (as you like it) Setting display condi- The map displays can be changed directly from the remote control. Just tions press and hold the POS. button on the Tips remote control, the display changes: NORTH UP ↔ HEAD-UP Press the MENU button to display the main menu.

  • Page 44: Setting Guidance Conditions

    When "ON" is selected, the unit estimates the arrival time and journey time to the destination when the function does not work. route to the destination has been calculated. The Consult your Alpine dealer about the Tips analog clock displays the estimated arrival time and audio unit combined.

  • Page 45: Direction Correction

    The graphic screen appears in the Direction correction display for the selected menu. Tilt the joystick to the right or left to If the actual direction of your vehicle and the increase or decrease the average direction of the present vehicle position icon on speed respectively.

  • Page 46: Screen Position Adjustment

    Customizing (as you like it) Screen position adjustment Distance coefficient For some TV monitors that can be connected to The navigation system measures the distance the navigation system, the screen display will with the speedometer pulses. Since the speed- be out of place. Adjust the display position to ometer pulses depend on the vehicle manufac- match the TV monitor you connect to the turer and the tyre size, when you buy a new...

  • Page 47: Useful Hints

    Useful Hints Viewing GPS screens Viewing odometer GPS satellite information being received is The odometer displays the route distance/time displayed on the screen. If the error for the travelled since the power to the navigation current vehicle's position is too large, check system was switched on.

  • Page 48: Viewing Dvd Rom Information

    Useful Hints Viewing DVD ROM in- formation You can look at the information about the DVD ROM. Press the MENU button to display the main menu. Select "Inform" from the main menu, then select "DVD-ROM INFO" from the sub- menu and press ENTER. The DVD ROM information is displayed.
  • Page 49 Notes...

  • Page 50: Reference

    Reference Reference Buttons and functions of remote controls RUE-4131 RUE-4167 ENTER POS. DEST. ROUTE A.PROC A.PROC A.PROC A.PROC A.PROC DEFEAT MUTE ROUTE POS. DEST. LO.PT. LO.PT. ZOOM ZOOM TUNER DISC V.SEL " POWER " POWER NAVI NAVI OFF POWER (with flap lid opened) (with flap lid opened) &...
  • Page 51 Button RUE-4131 Description RUE-4167 Tilting the joystick selects items from menus and moves the map in eight directions. ENTER Pressing the ENTER button selects a highlighted item in the menu. Displays the menu screen. Returns the navigation system to the previous searching. Press this button for voice guidance.

  • Page 52: In Case Of Difficulty

    If you encounter a problem, please review the items in the following checklist. This guide will help you isolate the problem if the system is at fault. Otherwise, make sure the system is properly connected or consult your authorized Alpine dealer. Symptom...
  • Page 53 If this message appears Various messages are displayed on the monitor screen during operation. In addition to the mes- sages telling you the current status or providing guidance for the next operation, there are also the following error messages. If one of these error messages is displayed, carefully follow the instruc- tions in the solution column.

This manual is also suitable for:

Nvd-v001Smart map pro 1.00

Table of Contents
