Configuring from a browser
Most of the settings above can be done from a standard web browser. From any standard web
browser, enter the IP address of the phone as the URL. You will get the home page of the LP5100
phone. The password expected to do configuration changes is the same password you use to enter
the Administration menu on the phone.
Navigating through the configuration settings from a browser should be straightforward. So, we
will not go into details here.
4.2.2.2. Ordering Information
The LP5100 phones can be ordered from Ingram Micro and TechData. In order to order these
phones, resellers have to have a reseller account with the distributor. Siemens does not have any
special authorization requirements. Any reseller with an account with the distributors will be able
to order the phones. Please contact your distributor for information on part numbers and other
details.
4.2.3. AltiView integrated with NetMeeting
This is the Soft Phone solution for IP Extension and this is probably the least expensive option.
AltiView 4.0 provides an option (called IP Extension Integrated with NetMeeting) that allows it
to use NetMeeting as the IP extension. To use this option, all you need is a sound card and a head
set (Plantronics headset is recommended) that connects to the sound card. You should not use a
microphone and speakers since this would cause the speaker's output to be fed back to the
microphone and cause severe echoes. The downside is that the PC's CPU will be used for voice
compression / decompression, so if you are running processor-intensive applications, it will affect
the voice quality.
4.2.3.1. Configuration
You should have NetMeeting 3.01 and AltiView 4.0 installed on the client PC in order to use this
option. No special configuration settings are required. You just check the option IP Extension
Integrated with NetMeeting when starting AltiView and you are ready to go.
To make a call, use AltiView's Dial function. When your extension receives a call, a dialog box
pops up that asks you if you wish to accept this call. If you choose 'Yes', you will be connected to
the caller via the headset. You can use AltiView's call control functions such as transfer just as
usual.
4.2.3.2. Ordering Information
You need the following components to use NetMeeting with AltiView as your IP Extension:
1. AltiView 4.0 - You can order this along with the AltiWare OE server software. You will
need one Session license for each simultaneous client connection to the server.
2. NetMeeting 3.01 - You can download it for free from Microsoft website
http://www.microsoft.com/downloads/release.asp?ReleaseID=10494
3. Plantronics LS1 headset - You can pick it up from any electronics retail store or order
online from Plantronics website
IP Extensions in AltiWare OE 4.0, © Copyright 2000, AltiGen Communications, Inc
http://buy.plantronics.com/
Page 10/11
