AltiWare OE 4.5 Errata
This sheet supplements the AltiWare OE 4.5 System Installation and Administration
Manual, released 3/2002.
•
Page 54—IP Port Support. AltiWare IP port density is increased to 78 ports.
•
Page 135—DID Number Length. The number of digits needed to match a DID
(Direct Inward Dialing) number, with a range of 2 - 16.
Each extension can be assigned a DID number. A DID number does not have a
fixed length. For example, the DID number length is 4; the extension DID number
- 2529299.
Depending on the service contract with the Central Office (CO), the DID trunk can
send all 7 digits (2522999) or just the last 4 digits (2999). If this DID Number
Length option is set to 4, the system always tries to match the last 4 digits received
to the last 4 digits of a DID number, regardless of what is received.
Note:
To accommodate future growth and minimize disturbance, it is recommended
that the length of the DID numbers assigned to an extension be greater than or
equal to this DID Number Length. However, it is not necessary to use the DID
Number Length when routing via tie trunks.
•
Page 135—First Digit Assignment. These define how the system responds to the
first digit dialed by the user. If a particular digit is grayed out—not available—that
means it cannot be used in the country location selected in the General window.
The drop-down list options for each digit are as follows in descending order—
Extension, Trunk Access, Operator, Invalid (no action), IP Trunk Access, Route
Access
•
Page 177—Firewall Configuration for more than one IP board. From 49152 to
N, where N = 49152 + (62 * number of boards) - 1.
•
Page 186—Triton T1/PRI Board ID. The Board ID must be in the range of 0-5.
•
Pages 204—Quantum Trunk Line Properties Window. New screenshot for
Figure 3.
