PID: 30430 Rev 3.51 March 2006
Parameter/OPN
Model Number
CPUID 8000_0001h EBX [11:6]
(BrandID)
CPUID 8000_0001h EAX [31:0]
(CPUID)
FID/VID Status MaxFID Field
FID/VID Status StartFID Field
L2 Cache Size
Max HyperTransport™ Frequency
Max P-State
FID/VID Status MaxVID Field
FID/VID Status StartVID Field
VID Code
VID_VDD
Thermal Design Power
Intermediate P-State #1
VID Code / VID_VDD
Thermal Design Power
Intermediate P-State #2
VID Code / VID_VDD
Thermal Design Power
Intermediate P-State #3
VID Code / VID_VDD
Thermal Design Power
Intermediate P-State #4
VID Code / VID_VDD
Thermal Design Power
Intermediate P-State #5
VID Code / VID_VDD
Thermal Design Power
Intermediate P-State #6
VID Code / VID_VDD
Thermal Design Power
Min P-State
VID Code / VID_VDD
Thermal Design Power
The notes for this table appear on page 90.
AMD Athlon™ 64 Processor Power and Thermal Data Sheet
Notes ADA3800DAA5BV
3800+
05h
1
00020FB1h
1
0Ch
2
2 0Ch
1 MB
1000 MHz
2000 MHz
2, 6 08h
2, 6 0Ah
0Ah
3 1.300 V 1.350 V
4, 7 89.0 W
5 1800 MHz
3 0Ah 1.300 V
4, 7 84.6 W
5 N/A
3
4, 7
5 N/A
3
4, 7
5 N/A
3
4, 7
5 N/A
3
4, 7
5 N/A
3
4, 7
1000 MHz
3 12h 1.100 V
4, 7 40.1 W
AMD Athlon™ 64 X2 Dual Core Processor
ADA4200DAA5BV
4200+
05h
00020FB1h
0Eh
0Eh
1 MB
1000 MHz
2200 MHz
08h 06h
06h
08h 0Ah 08h
08h 0Ah 08h
1.300 V 1.350 V
89.0 W
2000 MHz
0Ah 1.300 V
84.6 W
1800 MHz
0Ch 1.250 V
70.9 W
N/A
N/A
N/A
N/A
1000 MHz
12h 1.100 V
37.6 W
ADA4600DAA5BV
4600+
05h
00020FB1h
10h
10h
1 MB
1000 MHz
2400 MHz
08h 06h
0Ah 08h
0Ah 08h
1.300 V 1.350 V
110.0 W
2200 MHz
0Ah 1.300 V
105.6 W
2000 MHz
0Ch 1.250 V
89.1 W
1800 MHz
0Eh 1.200 V
74.8 W
N/A
N/A
N/A
1000 MHz
12h 1.100 V
46.6 W
