PID: 30430 Rev 3.51 March 2006
Parameter/OPN
Tcase Max
Tcontrol Max
Tambient
Thermal Resistance (case-amb)
Thermal Profile
Max P-State
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #1
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #2
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #3
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #4
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #5
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #6
VID_VDD
IDD Max
Thermal Design Power
Min P-State
VID_VDD
IDD Max
Thermal Design Power
Halt/Stop Grant
IDDC1 Max @ Max P-State
IDDC1 Max @ Min P-State
I/O Power
S3
I/O Power
The notes for this table appear on page 59.
AMD Athlon™ 64 Processor Power and Thermal Data Sheet
Notes ADAFX55DAA5BN
1, 13 49°C to 63°C
2 70°C
40°C
0.22°C/W
14
G
2600 MHz
3 1.350 V 1.400 V
74.9 A
4 104.0 W
11 N/A
3
4
11 N/A
3
4
11
N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
1200 MHz
3 1.100 V
35.7 A
4 42.2 W
5 34.8 A
6 7.1 A
8, 12 2.9 W
7
7, 9, 12 500 mW
AMD Athlon™ 64 FX Processor
ADAFX57DAA5BN
49°C to 63°C
70°C
40°C
0.22°C/W
G
2800 MHz
1.350 V 1.400 V
74.9 A
104.0 W
N/A
N/A
N/A
N/A
N/A
N/A
1200 MHz
1.100 V
36.8 A
43.4 W
34.8 A
7.1 A
2.9 W
500 mW
