PID: 30430 Rev 3.51 March 2006
Parameter/OPN
Tcase M ax
Tcontrol M ax
Tambient
Thermal Resistance (case-amb)
Max P-S tate
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #1
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #2
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #3
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #4
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #5
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #6
VID_VDD
IDD M ax
Thermal Design Power
Min P-S tate
VID_VDD
IDD M ax
Thermal Design Power
Halt/S top Grant
IDDC1 M ax @ M ax P-State
IDDC1 M ax @ M in P-State
I/O Power
S 3
I/O Power
The notes for this table appear on page 74.
AMD Athlon™ 64 Processor Power and Thermal Data Sheet
Notes S DA3100AIO3BX
1 69°C
2 70°C
42°C
0.45°C/W
1800 M Hz
3 1.400 V
40.6 A
4 59.0 W
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
1000 M Hz
1.100 V
3
17.7 A
4 21.7 W
5 21.6 A
6 4.6 A
8, 12 2.2 W
7
7, 9, 12 500 mW
AMD Sempron™ Processor
S DA3300AIO2BX S DA3400AIO3BX
69°C
70°C
42°C
0.45°C/W
2000 M Hz 2000 M Hz
1.400 V
40.6 A
59.0 W
1800 M Hz 1800 M Hz
1.350 V
35.1 A
49.6 W
N/A
N/A
N/A
N/A
N/A
1000 M Hz 1000 M Hz
1.100 V
16.8 A
20.7 W
21.6 A
4.6 A
2.2 W
500 mW
69°C
70°C
42°C
0.45°C/W
1.400 V
40.6 A
59.0 W
1.350 V
35.1 A
49.6 W
N/A
N/A
N/A
N/A
N/A
1.100 V
16.8 A
20.7 W
21.6 A
4.6 A
2.2 W
500 mW
