PID: 30430 Rev 3.51 March 2006
Parameter/OPN
M odel Number
CPUID 8000_0001h EBX [11:6]
(BrandID)
CPUID 8000_0001h EAX [31:0]
(CPUID)
FID/VID Status M axVID Field
FID/VID Status M axFID Field
FID/VID Status StartVID Field
FID/VID Status StartFID Field
AltVID Code / VID_VDD
L2 Cache Size
Max P-S tate
VID Code / VID_VDD
Thermal Design Power
Intermediate P-S tate #1
VID Code / VID_VDD
Thermal Design Power
Intermediate P-S tate #2
VID Code / VID_VDD
Thermal Design Power
Intermediate P-S tate #3
VID Code / VID_VDD
Thermal Design Power
Intermediate P-S tate #4
VID Code / VID_VDD
Thermal Design Power
Intermediate P-S tate #5
VID Code / VID_VDD
Thermal Design Power
Intermediate P-S tate #6
VID Code / VID_VDD
Thermal Design Power
Min P-S tate
VID Code / VID_VDD
Thermal Design Power
The notes for this table appear on page 79.
AMD Athlon™ 64 Processor Power and Thermal Data Sheet
Notes TMS MT34BQX5LD
M T34
0Bh
1
00020F42h
1
2 08h
2 0Ah
2 16h
2 00h
3, 4, 5 18h 0.850 V
1 M B
1800 M Hz
4, 5 0Ah 1.200 V
6 24.0 W
7 1600 M Hz
4, 5 0Ch 1.150 V
6 19.9 W
7 N/A
4, 5
6
7 N/A
4, 5
6
7 N/A
4, 5
6
7 N/A
4, 5
6
7 N/A
4, 5
6
800 M Hz
4, 5 16h 0.900 V
6 7.9 W
AMD Turion™ 64 Mobile Technology
TMS MT37BQX5LD
M T37
0Bh
00020F42h
08h
0Ch
16h
00h
18h 0.850 V
1 M B
2000 M Hz
0Ah 1.200 V
25.0 W
1800 M Hz
0Ch 1.150 V
20.9 W
1600 M Hz
0Eh 1.100 V
17.5 W
N/A
N/A
N/A
N/A
800 M Hz
16h 0.900 V
7.9 W
78
