PID: 30430 Rev 3.51 March 2006
Parameter/OPN
Tcase M ax
Tcontrol M ax
Tambient
Thermal Resistance (case-amb)
Thermal Profile
Max P-S tate
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #1
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #2
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #3
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #4
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #5
VID_VDD
IDD M ax
Thermal Design Power
Intermediate P-S tate #6
VID_VDD
IDD M ax
Thermal Design Power
Min P-S tate
VID_VDD
IDD M ax
Thermal Design Power
Halt/S top Grant
IDDC1 M ax @ M ax P-State
IDDC1 M ax @ M in P-State
I/O Power
S 3
I/O Power
The notes for this table appear on page 48.
AMD Athlon™ 64 Processor Power and Thermal Data Sheet
Notes ADA3200DKA4CG
49°C to 65°C
1, 13
2 70°C
42°C
0.34°C/W
14 B
2000 M Hz
3 1.350 V
47.5 A
4 67.0 W
11 1800 M Hz
3 1.350 V
45.8 A
4 64.7 W
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
1000 M Hz
1.100 V
3
23.4 A
4 28.6 W
5 25.8 A
6 8.0 A
8, 12 2.9 W
7
7, 9, 12 500 mW
