AMD ADA3000DAA4BW - Athlon 64 1.8 GHz Processor User Manual page 42

PID: 30430 Rev 3.51 March 2006
Parameter/OPN
Tcase Max
Tcontrol Max
Tambient
Thermal Resistance (case-amb)
Max P-S tate
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #1
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #2
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #3
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #4
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #5
VID_VDD
IDD Max
Thermal Design Power
Intermediate P-State #6
VID_VDD
IDD Max
Thermal Design Power
Min P-State
VID_VDD
IDD Max
Thermal Design Power
Halt/S top Grant
IDDC1 Max @ Max P-State
IDDC1 Max @ Min P-State
I/O Power
S 3
I/O Power
The notes for this table appear on page 48.
AMD Athlon™ 64 Processor Power and Thermal Data Sheet
Notes ADA3000DIK4BI
1 65°C
2 70°C
42°C
0.34°C/W
1800 MHz
3 1.400 V
9 45.8 A
4, 9 67.0 W
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
11 N/A
3
4
1000 MHz
3 1.100 V
16.5 A
4 21.0 W
5 36.8 A
9.3 A
6
8, 12 2.9 W
7
7, 9, 12 750 mW
AMD Athlon™ 64 Processor
ADA3200DIK4BI ADA3500DIK4BI
65°C
70°C
42°C
0.34°C/W 0.34°C/W
2000 MHz 2200 MHz
1.400 V
45.8 A
67.0 W
1800 MHz 2000 MHz
1.350 V
39.3 A
56.0 W
N/A 1800 MHz
N/A
N/A
N/A
N/A
1000 MHz 1000 MHz
1.100 V
16.5 A
21.0 W
36.8 A
9.3 A
2.9 W
750 mW
65°C
70°C
42°C
1.400 V
45.8 A
67.0 W
1.350 V
39.3 A
56.0 W
1.300 V
33.2 A
46.0 W
N/A
N/A
N/A
N/A
1.100 V
15.5 A
20.0 W
36.8 A
9.3 A
2.9 W
750 mW
