Removing Simms - Cisco RSP2 - Route Switch Processor 2 Installation And Configuration Manual

Table 13
Produce Numbers
MEM-RSP-24M
MEM-RSP-32M (=)
MEM-RSP-64M (=)
MEM-RSP-128M(=)
1. The 32-MB DRAM configuration is the default DRAM configuration for the RSP2, as well as the minimum DRAM
To prevent system and memory problems when you install DRAM, the RSP2 DRAM SIMMS must be
Caution
3.3V devices. Do not attempt to install higher-voltage devices in the RSP2 SIMM sockets. Handle the
SIMM by the card edges only, and avoid touching the memory module, pins, or traces (the metal fingers
along the connector edge of the SIMM). (See
Figure 13
Note Use only SDRAM SIMMs from Cisco Systems. A Cisco manufacturing part number appears on each
SDRAM SIMM.

Removing SIMMs

This section discusses the procedure for removing SIMMs from your RSP2.
Use this procedure to remove the existing SIMMs:
Step 1 Turn off the system power and follow the steps in the
Step 2 Place the RSP2 on an antistatic mat or pad and ensure that you are wearing an antistatic device, such as
a wrist strap.
Step 3 Position the RSP2 so that the faceplate is toward you and the bus connectors are away from you—this
position is shown in
Locate the DRAM SIMMs on the RSP2. The SIMMs occupy U33 and U21 (Bank 0) and U12 and U4
Step 4
(Bank 1). (See
72
RSP2 DRAM SIMM Configurations
Quantity
Two 8-MB SIMMs and
two 4-MB SIMMs
Two 16-MB SIMMs
Two 32-MB SIMMs
Two 32-MB SIMMs and
two 32-MB SIMMs
requirement for the HSA feature.
Handling the SIMM
Figure 2.
Figure 2.)
DRAM Sockets
U33 and U21 (Bank 0) and
U12 and U4 (Bank 1)
U33 and U21 (Bank 0)
U33 and U21 (Bank 0)
U33 and U21 (Bank 0) and
U12 and U4 (Bank 1)
Figure 13.)
"Removing the RSP2" section on page
Totals
24MB
1
32MB
64MB
128MB
15.
OL-4923-01 B0
