Product Description

This section discusses the following topics:
•
•
•
•
•
•
•
The RSP2 supports the VIP2 and the VIP4 in the Cisco 7505, Cisco 7507, and the Cisco 7513. (See
Figure 1
The RSP2 supports the VIP2 and VIP4 in the Cisco 7000 series routers, and the VIP2, VIP4, and the
VIP6-80 in the Cisco 7505, Cisco 7507, and the Cisco 7513 routers. The RSP2 is not supported on the
Cisco 7507-MX or the Cisco 7513-MX routers. The RSP2 is not available as an upgrade from an
RSP700, or an RSP1. You cannot upgrade to an RSP4/4+, RSP8, or RSP16 from the RSP2.
The RSP2 contains the central processing unit (CPU) and most of the memory components for the router.
The Cisco IOS software images reside in Flash memory, which is located on the RSP2:
•
•
For specific Cisco IOS software release compatibility, refer to the
Note
and to the Software Advisor at http://www.cisco.com/cgi-bin/Support/CompNav/Index.pl.
Storing the IOS software images in Flash memory enables you to download and boot from upgraded
Cisco IOS software images remotely or from software images resident in the RSP2 Flash memory,
without having to remove and replace read-only memory (ROM) devices.
The RSP2 also contains:
•
•
In addition to running the system software from DRAM, the RSP2 contains and executes the following
management functions that control the system:
•
•
•
OL-4923-01 B0
Obtaining Technical Assistance, page 86
-
Obtaining Additional Publications and Information, page 88
-
CPU, page 4
Memory Components, page 5
LEDs, page 6
PC Card Slots, page 7
Serial Ports, page 7
Specifications, page 7
System Software, page 8
and Figure 2.)
In the form of a single in-line memory module (SIMM) (U1 in
On up to two PC Cards (called Flash memory cards) that insert in the two PC Card slots (slot 0 and
slot 1) in the two PC Card slots (slot 0 and slot 1).
Most of the additional memory components used by the system, including 16-MB onboard Flash
memory and up to two Flash memory cards (16-MB, or 20-MB Flash memory card, with 20-MB
being the shipping default).
Air-temperature sensors for environmental monitoring. (All of the logic for the environmental
monitoring functions is contained on the router interface card.)
Sending and receiving routing protocol updates
Managing tables and caches
Monitoring interface and environmental status
Figure 2)
"System Software" section on page 8
