Restarting the System

When you turn the system power back on, verify that the system boots and resumes normal operation. If
you are restarting the system after upgrading the DRAM, expect that it will take the system longer to
complete the memory initialization portion of the boot sequence with more DRAM. (See the
System Startup Sequence" section on page
Follow these steps to verify that the RSP2 is installed and functioning properly:
Check the RSP2 connections to make sure they are secure:
Step 1
•
•
Observe the RSP2 LEDs. While the system initializes, the CPU halt LED on the RSP2 stays on. It goes
Step 2
off when the boot process is complete. As the RSP2 initializes each interface processor, the status LEDs
on each interface processor go on and off in irregular sequence.
For a Cisco 7507 or Cisco 7513 with HSA or HA configured, verify that the console terminal displays
Step 3
the system banner and startup screen as the system restarts.
•
•
20
The RSP2 is inserted all the way into its slot, and both the captive installation screws are tightened.
The console terminal is turned on and is connected to the console port.
The active console display should look similar to the following for a Cisco 7513 (note the RSP2 slots
indicated):
System Bootstrap, Version 11.1(2), RELEASED SOFTWARE
Copyright (c) 1986-1996 by cisco Systems, Inc.
SLOT 6 RSP2 is system master
SLOT 7 RSP2 is system slave
RSP2 processor with 16384 Kbytes of main memory
[additional displayed text omitted from this example]
Cisco Internetwork Operating System Software
IOS (tm) GS Software (RSP-JV), Version 11.1(4) [biff 51096]
Copyright (c) 1986-1996 by cisco Systems, Inc.
Compiled Mon 22-Jan-96 21:15 by biff
Image text-base: 0x600108A0, data-base: 0x607B8000
cisco RSP2 (R4600) processor with 16384K bytes of memory.
R4600 processor, Implementation 32, Revision 2.0
[additional displayed text omitted from this example]
8192K bytes of Flash PCMCIA card at slot 0 (Sector size 128K).
8192K bytes of Flash internal SIMM (Sector size 256K).
Slave in slot 7 is halted.
[additional displayed text omitted from this example]
The active console display should look similar to the following for a Cisco 7507 (note the RSP2 slots
indicated):
System Bootstrap, Version 11.1(2), RELEASED SOFTWARE
Copyright (c) 1986-1996 by cisco Systems, Inc.
SLOT 2 RSP2 is system master
SLOT 3 RSP2 is system slave
RSP2 processor with 16384 Kbytes of main memory
[additional displayed text omitted from this example]
Cisco Internetwork Operating System Software
IOS (tm) GS Software (RSP-JV), Version 11.1(4) [biff 51096]
62.)
