Booting Router-confg ..... [timed out]
If the display indicates that the process was successful, as shown in
Step 9
If the display indicates that the process failed, verify the name or address of the remote server and the
filename, and repeat the preceding steps. If you are unable to retrieve the configuration file, contact your
network administrator or see the end of this document for instructions on contacting technical assistance.
To ensure that the configuration file was retrieved correctly, issue the show startup-config command
Step 10
and look at the first line for the configuration file size. Match it with the file you retrieved from the TFTP
server. Following is an example:
Router# show startup-config
Using 1186 out of 126968 bytes
!
version 11.1
hostname Router
!
Router#
Step 11 Ensure that the startup configuration file stored in NVRAM is the default running configuration file used
by the system, and then enter the copy startup-config running-config command as follows:
Router# copy startup-config running-config
Router#
%SYS-5-CONFIG_I: Configured from memory by console
Router#
This completes the procedure for retrieving the saved configuration file.
Replacing and Upgrading DRAM SIMMs
This section describes how to remove and replace RSP2 DRAM SIMMs.
The default DRAM configuration is 32 MB, residing on two SIMMs (U33 and U21) on Bank 0. The
DRAM SIMM sockets are U33 and U21 (bank 0), and U12 and U4 (bank 1). (See
Do not mix memory sizes. If installing two SIMMs, both SIMMs must be the same size. If your router
Note
includes redundant RSPs, both RSPs should have the same memory size.
The total number of memory devices per SIMM differs for each manufacturer. The SIMMs in
Note
are generic representations of the actual DRAM SIMMs for your RSP.
Table 13
each configuration, and the DRAM banks they occupy. Note which banks are used, given the
combinations of available SIMM sizes and the maximum DRAM you require.
OL-4923-01 B0
lists the various configurations of DRAM SIMMs that are available, the number of SIMMs for
Step 8, proceed to the Step
Figure 2 and Table
Figure 2
10.
13.)
