Step 2
Router# copy tftp slot slot-number :
Address or name of remote host []? ip-address
Name of file to copy []? imagename <Return>
writing filename!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Destination filename? [ imagename1 ] <Return>
Accessing tftp:// host ip-address /file 'imagename' on
ip-address.. found !
11188128 bytes copied in 2280.664 secs (4906
bytes/sec)
Step 3
Router# configure terminal
Step 4
Router(config)# hw-module slot slot-number image
file-spec
Step 5
Router(config)# hw-module slot slot-number image
file-spec
OL-4923-01 B0
Uses TFTP to copy a high availability Cisco IOS
image onto the Flash memory card of the standby
RSP.
slaveslotslot-number—Specifies the Flash
•
memory card of the standby RSP.
Note: Step 1 and Step 2 are the same. Step 1
applies to the active RSP, and Step 2 applies to the
the standby RSP.
The router prompts you for the IP address of the
TFTP server.
• ip-address—Specifies the IP address of the
TFTP server that contains the new image
The router prompts you for the name of the image file
you are copying to the Flash memory card.
• imagename—Indicates the name of the image to
be loaded onto the Flash memory card.
The router prompts you to enter the name under
which you want the file to appear at the destination.
imagename1—Indicates the name of the image
•
as it appears at the destination.
Enters configuration mode.
Verifies that the specified image is compatible with
RPR and exists on the standby RSP. If a high
availability image is found, the running configuration
is updated.
• slot-number—Specifies the standby RSP slot
where the Flash memory card is located. Valid
numbers are slot 2 or slot 3 for a Cisco 7507
router or slot 6 or slot 7 for a Cisco 7513 router.
file-spec—Indicates the Flash device and the
•
name of the image on the standby RSP.
Verifies that the specified image is compatible with
RPR and exists on the active RSP. If a high
availability image is found, the running configuration
is updated.
slot-number—Specifies the active RSP slot
•
where the Flash memory card is located. Valid
numbers are slot 2 or slot 3 for a Cisco 7507
router or slot 6 or slot 7 for a Cisco 7513 router.
file-spec—Indicates the Flash device and the
•
name of the image of the active RSP.
