2. If both the Master and Slave LEDs are unlite, the board is inactive.
The Active/Standby switch has been deactivated in software. The reset button boots the system.

PC Card Slots

The RSP2 has two PC Card slots available. Either slot can support a Flash memory card or an
input/output (I/O) device. Type I and Type II PC Cards can be used in PC Card slot 0 and slot 1. Type
III PC Cards can be used in slot 1. Not all Flash memory cards that are commercially available are
supported, and not all I/O devices are supported.
Other Flash memory card limitations might apply. For additional Flash memory information, refer to the
Note
Flash memory configuration notes listed in the

Serial Ports

Two asynchronous serial ports on the RSP2, labeled Console and Auxiliary, allow you to connect
external terminal devices to monitor and manage the system. The console port is an Electronics
Industries Association/Telecommunications Industry Association (EIA/TIA)-232 receptacle (female)
that provides a data circuit-terminating equipment (DCE) interface for connecting a console terminal.
EIA/TIA-232 was known as recommended standard RS-232 before its acceptance as a standard by the
Note
Electronic Industries Association (EIA) and Telecommunications Industry Association (TIA).
The auxiliary port is an EIA/TIA-232 plug (male) that provides a data terminal equipment (DTE)
interface; the auxiliary port supports flow control and is often used to connect a modem, a channel
service unit (CSU), or other optional equipment for Telnet management.

Specifications

Table 3
Table 3
Description
Physical dimensions
Shipping weight
Operating temperature
Relative humidity
Storage temperature
OL-4923-01 B0
lists the physical specifications for the RSP2:
RSP Specifications
Specifications
The RSP2 occupies one RSP slot and can only be operated in a
Cisco 7500 series or RSP7000-equipped Cisco 7000 series router.
5 lb (2.25 kg)
32 to 104˚F (0 to 40˚C)
10 to 90 percent, noncondensing
–4 to 149˚F (–20 to 65˚C)
"Related Documentation" section on page 2.
7
