HSC-ADC-EVALC
Figure 4. HSC-ADC-EVALC Components (Bottom View)
HSC-ADC-EVALC SUPPORTED ADC EVALUATION BOARDS
Refer to the Analog Devices ADC capture board product page at
www.analog.com/FIFO
for a list of HSC-ADC-EVALC-compatible ADC
evaluation boards. Some legacy ADC boards may require interposer cards to facilitate proper pin mapping to the ADC capture board. If
needed, the interposer part number is noted in the compatibility table at
www.analog.com/FIFO
for the respective data converter.
Rev. 0 | Page 7 of 32
