Analog Devices HSC-ADC-EVALC User Manual page 29

Qty Reference Designator
17 L3 to L19
3 P1 to P3
13
R1, R3, R4, R34 to R39,
R61, R67, R77, R78
3 R15, R56, R74
1 R16
5 R17, R18, R23, R24, R50
10 R19 to R22, R46, R62 to
R66
1 R2
17 R25, R28, R31, R40 to
R45, R49, R52, R57,
R58, R71, R72, R75, R76
1 R26
2 R27, R33
1 R68
1 R29
0 R30
1 (R32), R79
1 R47
2 R48, R59
3 R5, R6, R73
2 R53, R70
1 R54
1 R55
2 R60, R69
2 R7, R8
1 S1
1 T1
1 U1
2 U10, U20
2 U11, U15
1 U12
1 U13
1 U16
1 U18
0 U19
2 U2, U17
1 U21
1 U3
1 U4
1 U5
Description
Ferrite chip, 220 Ω, 2 A, 0603, 100 MHz
Connector, 0.050 in × 0.050 in, Samtec
TFM series, 2R
Resistor, 100 Ω, 1/16 W, 1%, 0402 SMD
Resistor, 24 Ω, 1/16 W, 5%, 0402 SMD
Resistor, 75 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, 51.1 Ω, 1/16 W, 1%, 0402 SMD
Resistor, 499 Ω, 1/16 W, 1%, 0402 SMD
Resistor, 40.2 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, 3.74 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, 169 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, 249 Ω, 1/16 W, 1%, 0402 SMD
Resistor, 147 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, 226 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, 140 kΩ, 1/16 W, 1%, 0402 SMD,
do not install
Resistor, 107 kΩ, 1/16 W, 1%, 0402 SMD,
do not install R32
Resistor, 76.8 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, 100 kΩ, 1/16 W, 1%, 0402 SMD
Resistor 0 Ω, 1/16 W, 5%, 0402 SMD
Resistor 80.6 kΩ, 1/16 W, 1%, 0402 SMD
Resistor, low value, 1206 SMD, 0.04 Ω
Resistor, low value, 1206 SMD, 0.06 Ω
Resistor, 25.5K Ω, 1/16 W, 1%, 0402 SMD
Resistor array network, 8 Ω to 22 Ω chip
Fuse, PolySwitch SMT (PTC devices)
Choke, common-mode coils, wire-
wound type for large current
DLW5AH/DLW5BS series
(2014/2020 Size)
Virtex-4 FPGA
Voltage regulator, high accuracy, low IQ,
adjustable
Voltage regulator, high accuracy
ultralow IQ, 1.5 A
Crystal oscillator, 24 Mhz, 12 pF, SMD
1.8 V, 8 Mb, platform flash-in system
Voltage regulator, 1.5 A ultralow
dropout linear regulator
Crystal controlled oscillator (100 MHz
fixed frequency oscillator)
156.25 MHz low jitter saw crystal
oscillator, do not install
IC, constant frequency current-mode,
step-down, dc-to-dc controller in TSOT
IC, single inverter buffer/driver with
open-drain output
IC, EZ-USB FX2LP USB microcontroller
Switch, 5-position, SMT, DIP
IC, 128-bit I 2 C bus serial EEPROM
Rev. 0 | Page 29 of 32
Manufacturer
TDK
Samtec, Inc.
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
Panasonic/ECG
TT Electronics
TT Electronics
Panasonic/ECG
Panasonic
Tyco
Murata
Xilinx
Analog Devices
Analog Devices
ECS
Xilinx
National Semiconductor
Connor-Winfield Corp.
Epson Electronics America
Analog Devices
Fairchild Semiconductor
Cypress Semiconductor Corp.
CTS
Microchip
HSC-ADC-EVALC
Part Number
MPZ1608S221A
TFM-145-32-S-D-A
ERJ-2RKF1000X
ERJ-2GEJ240X
ERJ-2RKF7502X
ERJ-2RKF51R1X
ERJ-2RKF4990X
ERJ-2RKF4022X
ERJ-2RKF3741X
ERJ-2RKF1693X
ERJ-2RKF2490X
ERJ-2RKF1473X
ERJ-2RKF2263X
ERJ-2RKF1403X
ERJ-2RKF1073X
ERJ-2RKF7682X
ERJ-2RKF1003X
ERJ-2GE0R00X
ERJ-2RKF8062X
LRC-LR1206LF-01-R040-F
LRC-LR1206LF-01-R060-F
ERJ-2RKF2552X
EXB-2HV220JV
SMD250F-2
DLW5BSN191SQ2
XC4VFX20-10FFG672C
ADP3334ACPZ-REEL7
ADP3339AKCZ-2.5R7
ECS-240-12-4X
XCF08PFSG48C
LP38842S-1.2
CWX823-100.0M
EG-2121CA 156.2500M-PHPAL3
ADP1864AUJZ-R7
NC7SZ05M5X
CY7C68013A-128AXC
219-5MST
24LC00-I/SN
