System Board - HP Elite 7200 - Microtower PC Manual

Standard and Optional Boards
1 System board, includes heat sink backplate
Memory modules (DDR3, PC3-10600)
* 4 GB
* 2 GB
2 1 GB
Other boards
* ATI Radeon HD 6670 1-GB graphics adapter, full height
* ATI Radeon HD 6570 2-GB graphics adapter, full height
* ATI Radeon HD 6570 1-GB graphics adapter, full height
* ATI Radeon HD 6450 1-GB graphics adapter
* ATI Radeon HD 5570 1-GB graphics adapter
* ATI Radeon HD 5450 1-GB graphics adapter, standard bracket
* ATI Radeon HD 5450 512-MB graphics adapter, standard bracket
* ATI Radeon HD 4550 256-MB Dual Head graphics adapter
* ATI Radeon HD 4650 1-GB Dual Head graphics adapter
* nVidia GeForce GT440 3-GB graphics adapter, full height
* nVidia GeForce GT440 1.5-GB graphics adapter, full height
* nVidia GeForce GT420 2-GB graphics adapter, includes bracket
* nVidia GeForce GT405 1-GB graphics adapter, includes bracket
* nVidia GeForce GT320 1-GB graphics adapter, standard bracket
* nVidia GeForce GT230 1.5-GB graphics adapter, includes bracket
* nVidia GeForce G210 512-MB graphics adapter, includes bracket
* Intel Pro 1000 PT Gb Ethernet PCIe NIC, includes bracket
Intel Core processors (8-MB L3 cache, 1333-MHz FSB, quad core)
* i7-2600S, 2.8-GHz processor, 65W
* i7-2600, 3.4-GHz processor
Intel Core processors (4-MB L3 cache, 1333-MHz FSB, dual core)
* i5-2500S, 2.7-GHz processor, 65W
* i5-2500, 3.3-GHz processor
* i5-2400, 3.1-GHz processor
* i5-2400S, 2.5-GHz processor, 65W
* i3-2120, 3.3-GHz processor
* i3-2100, 3.1-GHz processor
* Not shown
HP Elite 7200 MT Series
636477-001
Miscellaneous Parts
1 Chassis fan
585157-001
2 Heat sink, Intel Class F, with thermal material
635803-001
3 Card reader, 22-in-1
635802-001
* Rubber feet
* Mouse, optical, carbon
640952-001
* Mouse, USB laser
638406-001
638405-001
*Not shown
LP = Low profile
638132-001
615792-001
601155-001
617079-001

System Board

584217-001
578174-001
638409-001
638408-001
632920-001
638407-001
615793-001
586381-001
586382-001
490367-001
638419-001
638415-001
638420-001
638414-001
638413-001
640953-001
638412-001
638411-001
System Board Connectors and Jumpers (position of some untitled
components may vary in location)
XU1 Processor
CPU_FAN1 Primary CPU fan
XMM4 DIMM 4 (Channel A)
XMM3 DIMM 3 (Channel B)
XMM2 DIMM 2 (Channel A)
XMM1 DIMM 1 (Channel B)
BATTERY Real-time-clock battery
PWR Main power
CMOSPW CMOS password header
SATA1 Primary HDD connector
SATA2 Primary ODD connector
SATA3 Secondary HDD connector
HOOD Hood sensor
SENSE
SATA4 Secondary ODD connector
JUSB1 USB connector
JUSB4 Front USB
640041-001
438741-001
638416-001
480032-001
370708-001
444740-001
570580-001
F_AUDIO Front audio connector
SPEAKER Speaker connector
CON1 Internal connector
J1394_1 Front 1394 port connector
PCIE_X1_3 PCIe X1, slot 3
PCIE_X1_2 PCIe X1, slot 2
PCIE_X1_1 PCIe X1, slot 1
PCIE_X16 PCIe X16 slot
SYS_FAN1 Primary chassis fan
AUDIO External audio connector
ATX_CPU 4-pin power connector
DVI DVI connector
USB_VGA USB/display connector
USB USB connectors
SPDIF_OU SP/DIF connector
T1
