Summary of Contents for HP Elite 7500 MT Business PC
Page 1
QuickSpecs HP Elite 7500 MT Business PC Overview HP ELITE 7500 MICROTOWER BUSINESS PC Two external 5.25" drive bays for optional optical drives 300W aPFC standard efficiency power supply Rear I/O includes: four USB 2.0 ports, SPDIF out, RJ-45 network interface, DVI-I & DVI-D video interfaces, , microphone jack, audio in/out jacks, 7.1 channel audio jacks...
Page 2
300W aPFC standard efficiency power supply Tool-less serviceability features for easier upgrades and repairs Protected by HP Services; terms and conditions vary by country; certain restrictions and exclusions apply DA - 14417 Worldwide — Version 5 — May 24, 2013...
QuickSpecs HP Elite 7500 MT Business PC Standard Features and Configurable Modules GRAPHICS Intel HD Graphics (integrated; varies by processor) AMD Radeon HD 7450 1GB DDR3 FH graphics card AMD Radeon HD 7570 2GB DDR3 FH graphics card NVIDIA GeForce GT 520 1GB DDR3 FH graphics card...
4GB DDR3-1600 DIMM (1x4GB) 6GB DDR3-1600 DIMM (4GB+2GB) 8GB DDR3-1600 DIMM (2x4GB) 16GB DDR3-1600 DIMM (4x4GB) SECURITY HP ProtectTools Security Suite for Small & Medium sized businesses SATA port disablement (via BIOS) Drive lock Removable media write/boot control Power-On password (via BIOS)
QuickSpecs HP Elite 7500 MT Business PC Standard Features and Configurable Modules SLOTS Three (3) PCI Express x1 Accessory Slots One (1) PCI Express x16 Graphics Slot One (1) PCI Express mini-Card Slot SERVICE AND SUPPORT 1 year standard on-site warranty and service: This limited warranty and service offering delivers parts, labor and on-site repair.
Windows® 7 Home Basic (64-bit)** Windows® Starter (32-bit)** FreeDOS Ubuntu For all Preinstalled operating systems HP provides Microsoft WHQL certified (where applicable) drivers on www.hp.com at the time of product announcement. *Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows 8 functionality.
Page 8
QuickSpecs HP Elite 7500 MT Business PC Operating Systems and Software People SkyDrive Photos Messaging Photos and Videos CyberLink YouCam CyberLink Media Suite CyberLink Power2Go CyberLink Label Print A/V Integration HP Connected Remote Audio Post Processing Beats Audio™ Games HP Games by WildTangent...
QuickSpecs HP Elite 7500 MT Business PC Technical Specifications Unit Environment and Operating Conditions General Unit Operating Guidelines Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is operated within the specified operating range.
Page 10
OpenGL 3.0 support Supported Display Resolutions and Refresh Rates NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP DA - 14417 Worldwide — Version 5 — May 24, 2013...
* Only supported when using a DisplayPort connection NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital connections ENVIRONMENTAL INFORMATION Eco-Label Certifications &...
Page 12
This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC. information This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC. This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of 1986).
Page 13
By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
Page 14
HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
