IBM OS/2 Installation Guide
for all Hewlett-Packard NetServers
NOTICE: The information in this document was last updated for the HP NetServer Navigator CD-ROM version E.10.00 or
L.16.00. If you don't have the E.10.00 or L.16.00 version CD-ROM and you're obtaining this document from the HP NetServer
web site as a reference to install an operating system, be sure to also check the HP NetServer web site for the latest available
drivers.
©Copyright Hewlett-Packard Company
March 19, 1999
(This document is only available in English.)
Introduction
The objective of this document is to help Hewlett-Packard customers install OS/2 on a HP
NetServer system. For additional information on Hewlett-Packard NetServers refer to the HP
Information Assistant on the HP NetServer Navigator CD-ROM.
Table of Contents
Before You Begin
Section 1. Installation Tips and Considerations
Tip 1) Extended Translation Setting
Tip 2) Extending Disk Capacity Beyond 1 GB
Tip 3) Formatting Disk Partitions Larger than 2 GB
Tip 4) Device Allocation Under OS/2
Tip 5) RAM Greater Than 192 MB
Tip 6) Performance Tuning
Tip 7) Troubleshooting System Hangs When Loading CONFIG.SYS
Tip 8) OS/2 Warp Server Installation Issues
Tip 9) How to View the Resources Used by an Adapter
Tip 10) How to Run the HPVGSET.EXE Utility from the Navigator CD-ROM
Tip 11) 4GB RAM Support in OS/2
Tip 12) HPFS386 Drive cache size issue on systems with 4GB RAM
Tip 13) When using HP NetRAID install the driver MRAID.ADD
Tip 14) Getting Trap 00D when booting OS/2
Tip 15) Getting Trap 008 during extensive disk/network I/O
Tip 16) Specific to E Series NetServers: How to boot from a NetRAID adapter while a
2910Bui SCSI card is present on the system
Tip 17) IRQ sharing can cause system hangs
Tip 18) Adaptec driver AIC7870.ADD 133496 12-Jan-1998 or later is required for 2940UW
with rev B chip set
