Hardware Changes

General Hardware Installation Sequence

To ensure the proper installation thin client hardware components:
1. Back up any data, if necessary.
2. If the thin client is powered on:
a. Turn the unit and any other attached devices off.
b. Disconnect the power cord from the wall outlet.
c. Disconnect any external devices or cables, such as an antenna or cable lock.
WARNING!
sure to disconnect the power cord from the wall outlet and allow the internal system components
to cool before touching.
WARNING!
telecommunications or telephone connectors into the network interface controller (NIC)
receptacles.
CAUTION:
equipment. Before beginning these procedures, ensure that you are discharged of static electricity
by briefly touching a grounded metal object. See
information.
3. Remove the secure USB compartment cover. See
Compartment Cover on page 13
4. Remove the stand, if it is installed. See
5. Remove the side access panel and metal side cover. See
Access Panel and Metal Side Cover on page 15
6. Remove any hardware that you will replace.
7. Install or replace equipment. For removal and replacement procedures, see the following
sections:
●
Installing the USB Device on page 18
● Installing the PCI Express Expansion Module and PCI Express Card on page 22
●
Removing and Replacing the Battery on page 18
ENWW
To reduce the risk of personal injury from electrical shock and/or hot surfaces, be
To reduce the risk of electrical shock, fire, or damage to the equipment, do not plug
Static electricity can damage the electronic components of the thin client or optional
for more information.
Electrostatic Discharge on page 34
Removing and Replacing the Secure USB
Removing the Stand on page 6
Removing and Replacing the Side
for more information.
General Hardware Installation Sequence
for more
for more information.
11
