Hardware Changes

General Hardware Installation Sequence

To ensure the proper installation thin client hardware components:
1. Back up any data, if necessary.
2. If the thin client is powered on:
a. Turn the unit and any other attached devices off.
b. Disconnect the power cord from the wall outlet.
c. Disconnect any external devices or cables, such as an antenna or cable lock.
WARNING!
sure to disconnect the power cord from the wall outlet and allow the internal system components
to cool before touching.
WARNING!
telecommunications or telephone connectors into the network interface controller (NIC)
receptacles.
CAUTION:
equipment. Before beginning these procedures, ensure that you are discharged of static electricity
by briefly touching a grounded metal object.
3. Remove the secure USB compartment cover. See
Compartment Cover on page 8
4. Remove the side access panel and metal side cover. See
Access Panel and Metal Side Cover on page 10
5. Remove any hardware that you will replace.
6. Install or replace equipment. For removal and replacement procedures, see the following
sections:
●
Installing the USB Device on page 9
●
Removing and Replacing the Battery on page 12
NOTE:
7. Replace the side access panel and metal side cover. See
Access Panel and Metal Side Cover on page
To reduce the risk of personal injury from electrical shock and/or hot surfaces, be
To reduce the risk of electrical shock, fire, or damage to the equipment, do not plug
Static electricity can damage the electronic components of the thin client or optional
Option kits include more detailed installation instructions.
Removing and Replacing the Secure USB
for more information.
for more information.
10.
General Hardware Installation Sequence
Removing and Replacing the Side
Removing and Replacing the Side
