Rear Panel Components
Figure 1-4
(1)
Wireless antenna*
(2)
Ethernet RJ-45 connector
(3)
Universal serial bus (USB) connectors (4)
(4)
DisplayPort connector
(5)
VGA connector
*Available on some models. Refer to the model-specific QuickSpecs at www.hp.com for details.
The wireless antenna allows you to send and receive wireless signals to communicate with wireless
local area networks (WLAN).
4
Chapter 1 Product Features
Rear panel components
(6)
PS/2 connectors (2)
(7)
Serial connector
(8)
Power connector
(9)
Power cord retention slot
ENWW
