Connecting Disk Drives to SATA HostRAID Controllers

1
Install your SATA disk drives, following the instructions in your system's documentation.
There are no jumpers or switches to set on the SATA controller or disk drives.
2
Connect each disk drive to a SATA port on the controller using a recommended SATA
cable. For cable information, see
3
When all disk drives have been installed and connected, close your computer cabinet, and
reconnect the power cord.

Checking Your Controller and Devices

Now that you have installed your controller and connected your disk drives, you can use the
ARC utility to check your controller and devices, as described below:
1
Turn on your computer.
2
When the Adaptec banner appears, press Ctrl+A to enter the Adaptec RAID Configuration
(ARC) utility.
3
If your drives have already been used in another system (even if not part of an array), select
Disk Utilities and format the drive. Otherwise, skip to
4
Select SATASelect (on SATA controller) and SerialSelect (on SAS controller) to verify the
hardware configuration of the controller and the drives.
Verify that all drives are shown. If anything appears to be missing, power down the
computer and check the connections.

Setting the Boot Controller

Note:
If your system contains only one bootable controller, or if you are using the 1225SA
controller that does not support bootable devices, proceed with
Most of the Adaptec HostRAID controllers support bootable disk drives and arrays. The
default setting of the HostRAID controller and system Setup allows you to install and boot
from either a disk drive connected to the motherboard, or from a drive or array connected to
the HostRAID controller. To enable the system to boot from either a disk drive or an array
connected to the HostRAID controller:
Note:
Selecting the boot controller is done using the system BIOS Setup Utility. Launching the
system BIOS Setup Utility varies depending on your computer model. Refer to your computer
documentation for instructions on how to access the system BIOS.
1
Enter the system BIOS Setup.
2
Navigate to the disk drive boot sequence.
3
Move the boot controller to the top of the list.
Chapter 4: Installing the HostRAID Controller and Disk Drives
page 29.
Step 4.
Creating an Array on page
l 32
38.
