B Specifications

HP 8 Internal Port SAS Controller Specifications

Table B-1 HP 8 Internal Port PCI-X SAS Controller Physical Specifications
Dimensions (excluding bracket)
Data Transfer Method
PCI Bus Speed
PCI Compatibility
Table B-2 HP 8 Internal Port SAS Controller General Specifications (PCI-X and Embedded)
Disk Drive and Enclosure Protocol Support
Architecture
SAS Connectors
Simultaneous Drive Transfer Ports
Port Transfer Rate
Software-Upgradeable Firmware
Maximum Capacity
Memory Addressing
Logical Drives Supported
RAID Support
16.8 x 6.4 x 1.6 cm
(6.6 x 2.5 x 0.6 in )
64-bit wide, PCI-X 133 MHz (1 GB/s maximum bandwidth)
PCI-X-133 and 3.3 volt PCI compatibility only
PCI-X and 3.3 volt PCI compatibility only
3 Gb/s SAS (Serial Attached SCSI)
64-bit
2 internal SFF8484 x4 Wide SAS Connectors
12 Gb/s per x4 Wide SAS Port (4 x 3 Gbps)
2 x4 Wide SAS Connectors
12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s)
Yes (4MB flashable ROM)
1.168TB (8 x 146GB SAS Drives)
64-bit, supporting servers with memory greater than 4 GB
Up to 2 Logical Volumes per RAID 1 array
Up to 10 disks total in all RAID volumes
RAID 1 (Mirroring)
