17. Reinstall the microprocessor tray in the server:
If you have other options to install or remove, do so now; otherwise, go to

"Completing the installation."

Completing the installation
To complete the installation, complete the following steps:
1. Make sure that all internal cables are properly routed through the server and
2. If you removed the top cover, place the cover-release latch in the open (up)
Note: Make sure that the air baffle lies flat and within the grooves on top of
the microprocessor heat sinks and microprocessor baffles and that the air
baffle remains in place while you close the microprocessor tray. You might find
it helpful to hold the air baffle in place with your thumbs while closing the
microprocessor tray.
a. Make sure that the microprocessor-tray release latch is open; then, push
the microprocessor tray into the server.
b. Close the tray levers and make sure that they are securely latched.
c. Press the microprocessor-tray release latch down.
d. Reinstall the fans and memory cards in the server.
that all cable retention devices are in place. If you have installed an optional
SAS backplane, make sure that the SAS signal cables have been routed
through the internal cable-management arm.
Top cover locking tab
Top cover
Front cover
position. Insert the bottom tabs of the top cover into the matching slots in the
server chassis. Press down on the cover-release latch to lock the cover in
place.
Cover release
latch
