Connecting the cables
You must turn off the server (see "Server power features" on page 12) before
connecting any cables to or disconnecting any cables from the server.
See the documentation that comes with optional devices for additional cabling
instructions. It might be easier for you to route cables before you install certain
options.
For details about the location and function of the input and output connectors, see
"Server controls, connectors, LEDs, and power" on page 8.
The following illustrations show the locations of the input and output connectors on
the server. Detailed cabling instructions for installing the server in a rack (rack
models only) are in the Rack Installation Instructions that come with the server.
Rear view
52
IBM System x3800 Type 8865: User's Guide
SP Ethernet 10/100
USB 1
Power-supply
Video
Gigabit Ethernet 1
Gigabit Ethernet 2
USB 2
System serial
SP serial
Mouse
Keyboard
IXA RS485
