Memory-card connectors
The following illustration shows the connectors on the memory card.
Memory-card LEDs
The following illustration shows the LEDs on the memory card.
The following illustration shows the top view of the memory card.
Light path diagnostics button
Light path diagnostics button power LED
Memory card error LED
Memory Port Power
Error
Memory Hot-Swap Enabled
DIMM 1
DIMM 2
DIMM 3
DIMM 4
DIMM 1 error LED
DIMM 2 error LED
DIMM 3 error LED
DIMM 4 error LED
Chapter 2. Installing options
17
