Installing the Remote Supervisor Adapter II SlimLine

An optional IBM Remote Supervisor Adapter II SlimLine can be installed only in its
dedicated connector on the I/O board.
Note: If a Remote Supervisor Adapter II SlimLine is installed in the server, when
you turn on the server for the first time, the server might appear to be unresponsive
for an unusual length of time (one minute to several minutes). This is normal
operation while the Remote Supervisor Adapter II SlimLine gathers information
about the server.
To install a Remote Supervisor Adapter II SlimLine, complete the following steps:
1. Read the safety information that begins on page v and "Installation guidelines"
2. Turn off the server and peripheral devices, and disconnect the power cords and
3. Remove the top cover.
4. Carefully grasp the Remote Supervisor Adapter II SlimLine assembly by its top
5. Press the assembly firmly into the connector and under the retention latch on
If you have other devices to install or remove, do so now; otherwise, go to
"Completing the installation" on page 20.
on page 7.
all external cables necessary to install the device.
Attention: When you handle static-sensitive devices, take precautions to
avoid damage from static electricity. For details about handling these devices,
see "Handling static-sensitive devices" on page 9.
Remote Supervisor Adapter II
SlimLine
edge or upper corners, and align it with the guide and the connector on the I/O
board.
Attention: Incomplete insertion might cause damage to the I/O board or the
adapter.
the guide.
Remote Supervisor Adapter II
SlimLine guide
Retention latch
Chapter 2. Installing options
