To install a hot-swap hard disk drive, complete the following steps:
1. Read the safety information that begins on page v and "Installation guidelines"
2. Remove the filler panel from one of the empty hot-swap bays.
3. Make sure that the tray handle is open; then, install the hard disk drive into the
Notes:
1. When you turn on the server, check the hard disk drive status LEDs to make
2. If the server will be configured for RAID operation using a ServeRAID
10
IBM System x3755 Types 8877 and 7163: Installation Guide
Filler panel
Drive tray assembly
Drive handle
(in open position)
on page 7.
hot-swap bay.
sure that the hard disk drive is operating correctly.
If the amber hard disk drive status LED for a drive is lit continuously, that drive
is faulty and must be replaced. If the green hard disk drive activity LED is
flashing, the drive is being accessed.
controller, you must configure the disk arrays before you install the operating
system. See the ServeRAID documentation on the IBM ServeRAID Support CD
for additional information about RAID operation and complete instructions for
using ServeRAID Manager.
™
