Viewing Connection
Viewing System
Downloaded from www.Manualslib.com
Under System Summary, click Connection Status to view a summary of the
Status Bridge's current connection information. See Table 8 on page 27 for details.
Under System Summary, you can view the following information:
Summary
Table 14 System Summary Page
Property
Device Name
Device Location
Country Code
Transmit Power
MAC Address
Serial Number
Firmware Version
DHCP Client
IP Address
Subnet Mask
Data Preamble
System Up Time
Date Manufactured
Click Refresh to update the information.
manuals search engine
Using the Configuration Management System
Description
The name assigned to the Bridge. You can
change the default name to one of your
choice by clicking System Properties under
System Configuration.
If you use the default device name, entering
the location is optional.
The Country Code determines the available
channels and transmission power level
based on regulatory restrictions in the
county where the Bridge is installed.
The level of transmission power (100%,
50%, 25%, 12%, or Min).
You can change this setting by clicking
Wireless Network under System Configuration.
The MAC address of the Bridge.
The serial number of the Bridge.
The version of firmware the Bridge is
currently using.
Determines if the Bridge obtains its
IP address from the DHCP server on the
network.
The IP address of the Bridge. You can
change this address by clicking IP Network
under System Configuration.
The subnet mask address of the Bridge.
You can change this address by clicking IP
Network under System Configuration.
The data preamble setting (Short [Enhanced
performance] or Long [Wi-Fi Interoperable]).
To change this setting, click Wireless
Network under System Configuration.
The elapsed time since the Bridge booted up. Day 0, 0:00:00
The date the Bridge was manufactured.
47
Default Value
3Com WWB
None
Varies
100%
N/A
N/A
N/A
On
Varies
Varies
Long
N/A
