Condition
Match calls
0
incoming on port
"1" leased line
group "2"
1 Match calls
incoming on port
"2" leased line
group "1"
Match calls
2
incoming on port
"Any" leased
line group "Any"

IP to ISDN dial plan (leased line mode)

The dial plan shown below is the IP to ISDN dial plan:
#
Condition
0 Called number
matches
"98(D)(D)(D+)"
Match any
1
incoming call
Cisco TelePresence ISDN Gateways v2.0 Online help (Printable format)
Maximum call
Action
bandwidth
Call this number <use default
"10.2.1.12 ! 555" value>
Enter the auto <use default
attendant + TCS-
value>
4
Call this number <use default
"10.2.1.10" value>
Action TCS-4 extension
Call port $1 $3
leased line group
$2
Call port "2"
leased line
group"3"
Example dial plan rules
Description
This rule matches any call arriving
from the ISDN network using leased
line group 2 on ISDN port 1 and
forwards it to the auto attendant on
the MCU at 10.2.1.12. (The MCU's
auto attendant is configured with
Numeric ID 555.)
This rule matches any call arriving
from the ISDN network using leased
line group 1 on ISDN port 2 and
forwards it to the auto attendant
which dials out using the TCS-4
extension.
This rule matches any call arriving
from the ISDN network (that has not
matched either of the above two
rules) and forwards it to, for example
an operator, at 10.2.1.10
Description
This rule matches any call to a four-
digit number beginning 98. The
dialed digits also provide the ISDN
port number, the leased line group,
and the TCS-4 extension. For
example, if the called number is
9812777, the call will be made on
ISDN port 1 using leased line group
2, with TCS-4 extension 777.
This rule matches any call that does
not match the first rule in the dial
plan. In this example, calls to port 2
leased line group 3 will be answered
by an operator.
