  • Page 2 Notice © Copyright 2002 Welltech Computer Co., Ltd. All intellectual property rights in this publication are owned by Welltech Computer Co., Ltd. and are protected by Republic of China copyright laws, other applicable copyright laws and international treaty provisions. Welltech Computer Co., Ltd. retains all rights not expressly granted.

  • Page 3: Table Of Contents

    3.11 P ...................51 REFIX ONFIGURATION 3.12 R ....................54 OUTING ABLE 3.12.1 Change the default routing ...............55 3.12.2 Add a new Routing Table ................57 3.13 FXO P ....................59 ASSWORD 3.14 IP P S....................60 ACKET Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 4 4.2.14 [prefix] ......................94 4.2.15 [pbook]......................95 4.2.16 [voice] .......................97 4.2.17 [support] ....................99 4.2.18 [phone]....................101 4.2.19 [tone].......................103 4.2.20 [fxopwd]....................105 4.2.21 [record] ....................106 4.2.22 [tos]......................114 4.2.23 [ddns]...................... 114 4.2.24 [pt] ......................116 4.2.25 [rom] ....................... 116 Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 5: Release Mar

    FXSO H.323 Gateway User Manual Document Ver.: 2.2 Release Mar., 2004 4.2.26 [passwd]....................118 Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 6: Steps In Configuration

    To explain the meaning of the command in the STEP 4 command line interface and example the usage of Command the command. List To get more usages or configuration in this step and study about the command line configuration. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 7: Start Up

    Network Trunk side Trunk side Extension Extension  FXO ports can connect with PSTN Line or Extension Line of PBX  FXS ports can connect with Phone Set or Trunk Line of PBX Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 8: Features And Specification

    G.168/165-compliant adaptive echo cancellation Dynamic Jitter Buffer Completed voice band signaling support Provide In-band or Out-band DTMF generation/detection Provide call progress tone Management Feature TELNET/Console port and Web Browser configuration Certification UL, CE, FCC FXS Features Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 9 Support auto-attendant (Tone or voice greeting) PSTN polarity reversal detection Provide 2 dial tone to PSTN Disconnect tone detection Asking ping function with the inside or outside calls Environmental Operation temp:0°C to 40°C Humidity: 10% to 90% (Non-condensing) Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 10: Accessories And Equipment

     The voice gateway in 2/4 FXS ports models and two RJ-45 connector (WAN and LAN).  The AC adapter.  The CD of user manual.  The connection cable in RS-232 interface. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 11: Appearance

    2. ACT- LED light on and flash when Ethernet data is being transmitted / received. LAN: Switch to another device, such as PC 1. Line- LED light on means Gateway is physically connected to the Ethernet Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 12 LAN/WAN: 10/100 Base-T; RJ-45 socket, complied with ETHERNET 10/100base-T. The pin-out is as following: PIN 1, 2: Transmit PIN 3, 6: Receive 2. COM: RS232 console port (DB-9pin male connector) Note: use straightforward cable to connect to your computer. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 13 RJ-11 connector, FXS interface is for connecting the analog phone sets or trunk line of PABX. 4. LINE: RJ-11 connector, FXO interface is for connecting the extension line of PABX or PSTN Line. 5. 12V DC: Input AC 100V~120V;output DC12V. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 14: How To Setup And Connect Basically

    2. One standard straightforward RS-232 cable (female connector to Gateway side). 3. Analog telephone sets. 4. PBX extension Lines or PSTN Lines. 5. Software tools (a) Hyper Terminal, TELNET, Web Browser. (b) Gatekeeper (optional). Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 15: Ip Environment Setting

    Turn on your computer and configure the network parameter as follow: Go to the start menu and enter the setting area. Click control panel. Enter the network configuration. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 16 Figure 2.1: Network Configuration Select the Property of the LAN card. Setup the ip address, subnet mask and default gateway as below: Figure 2.2: Configure the network Click OK after you finished the network setup. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 17: Network Configurations In Your Gateway

    The default ip address, netmask and default gateway address of the gateway is 10.1.1.3, 255.255.0.0, 10.1.1.254. 2.3 Network configurations in your gateway Key in the ip address of the gateway (http://10.1.1.3) with the browser Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 18 WEB configuration. (Username: root ; No password) Figure 2.3: Login the username and password You will enter the main page of the configuration after key in the login name and password correctly: Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 19: Static Ip Address

    Press the Network Interface to configure the networking of your gateway: Figure 2.5: The Network Interface 2.3.1 Static ip address Please get the correct ip address, netmask and default gateway address from your ISP first. Press the OK button if you finished. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 20 Document Ver.: 2.2 Release Mar., 2004 Figure 2.5: Configure the static ip address Press the commit if you finish the configuration. Figure 2.6: Commit the data Press the reboot if you want the configuration executed. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 21: Dhcp Mode

    Document Ver.: 2.2 Release Mar., 2004 Figure 2.7: Reboot the system 2.3.2 DHCP mode Change to the DHCP mode if you are using the cable modem or DHCP server. Figure 2.8: Enable the DHCP function Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 22: Pppoe Mode

    2.3.3 PPPoE mode Chang the PPPoE mode in the IP mode table. Figure 2.9: Chage to PPPoE mode Please commit the data and reboot the machine after you finished the configuration of PPPoE. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 23 FXSO H.323 Gateway User Manual Document Ver.: 2.2 Release Mar., 2004 Figure 2.10: Enter the PPPoE connection info Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 24: Making A Voip Call

    Enter the H323 Configuration table and change the mode to Peer-to-Peer. Figure 2.10: Configure the Peer-to-Peer mode Press the OK button which is on the buttom of this page to save the configuration. Figure 2.11: Press OK to save the data Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 25 FXSO H.323 Gateway User Manual Document Ver.: 2.2 Release Mar., 2004 Enter the Phone Book configuration table and configure the name, ip address and phone number of the destination. Figure 2.12: Phone Book Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 26 Press the “Add Data” button when you finished, and the new table will display on the first index if you press the Phone Book configuration button. Please Commit it and Reboot the system if the configuration is finished. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 27 Phone Book is only for the Peer-to-Peer mode. Fifty index support. 【The application in the drop and insert function】 Input (E164) Drop Insert Output Disable Disable 0200 Enable Enable ※ X – Do not enter any numbers Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 28: Configure The Gateway Into The Gk Routed Mode

    Press the OK button which is on the buttom of this page to save the configuration. Figure 2.16: Press OK to save the data Press the Commit Data and Reboot System buttons when you finished the configuration. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 29: The Type In Gk Routed Mode

    Do not support the one-stage Support the one-stage dialing dialing The default type of the all series Welltech gateway are Gateway type. But the LanPhone is the terminal type. You could change the type for your gateway but the LanPhone couldn’t.
  • Page 30 【Example – Gateway type】 Figure 2.17: Gateway Type configuration The prefix number is necessary if you configure it to be a gateway. The number of ports must be followed the prefix number. 【Example – Terminal type】 Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 31 FXSO H.323 Gateway User Manual Document Ver.: 2.2 Release Mar., 2004 Figure 2.18: Terminal Type configuration The prefix number is only for the gateway type and the number of ports could be configured in the different numbers. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 32: Advanced

     The WAN IP Address obtained from ADSL has two kinds of methods. One is fixed IP Address, while user applies for one or more fixed IP Addresses. Another is dynamic IP Address while user applies for dial-up connection way. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 33 Enter the IP address, Netmask and the default gateway in the network table. Please follow up your IP Sharing device. Figure 3.1: Network configuration Enable the ip sharing function and put the static ip address in the server address table. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 34 The IP change function is only for the special usage Figure 3.3: IP Change IP Change Function: The ip address of the IP Sharing Server Address will  use what you configured in that table if you disable the IP Change function. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 35 Please Commit it and Reboot the system if the configuration is finished. This chapter is focus on the DMZ function of the IP Sharing Device, Please get another application from our web site. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 36: Network Interface

     DNS primary – Users could define the primary DNS server address.  DNS secondary – Users could define the primary DNS server address.  SNTP – Enable the SNTP server registering function if user wants to get Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 37  IP Change – Enable this function if the WAN IP address of the IP sharing device is dynamic address. The IP change function could support the GK from Welltech only. Please pay more attentions about this function if your IP sharing device is using the dynamic IP address.

  • Page 38: H323 Configuration

    Support the GK mode only.  Default Gateway IP – All the calls will be routed to this destination if the destination couldn’t be found in the Phone Book configuration. Support the Peer-to-Peer mode only. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 39  H225 RAS Port – The RRQ sending port of this gateway. Support the GK mode only. From 1024 to 65535.  H225 Call Signal Port – The Call Signal Port sending of this gateway. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 40  Connection Timeout – The call will be timed out if the connect message didn’t received from the remote side. Support the GK mode only. From 1 to 20000.  H.235 Security Token – Support H235 security password for the registration. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 41: Line

    No Answer forward number is 123, and the forward time is 5 seconds. The call will be forwarded to the destination with 123 Copyright (c) 2002 Welltech Computer Co. Ltd. numbers when the origin port didn’t answer the call.
  • Page 42 FXSO H.323 Gateway User Manual Document Ver.: 2.2 Release Mar., 2004  Registration – To show the gateway registered on the GK or not.  Status – To show the port is busy or ready. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 43: System Configuration

     Prefix Disable Digits – Users could enter this digits for disable this function in this dialing. The Prefix, Prefix Switch and Prefix Disable Digits is a function. Users have to configure these three tables if this function is needed. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 44 But the number it transfer will be 10012345 (Gateway Prefix Keep). The transfer number will be 12345 if the Gateway Prefix function is enabled.  FXO type – Users could configure all the calls need the 2 stage dialing or not. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 45 If user dial the number of the FXO port, that will be the stage dialing.  Force 2 dial : Every calls will need the 2 stage dialing type.  Hardware Type – This will show the hardware detection type. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 46: Voice Setting

     Line3 (TEL 2) Volume – To configure the output gain (voice), input gain (input) and DTMF gain (DTMF) of the second FXS port.  Line4 (LINE 2) Volume – To configure the output gain (voice), input gain Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 47  Echo Canceller – To enable or disable the echo cancellation function.  Jitter Buffer – TO configure the Min or Max delay for the Jitter Buffer. The min is from 0ms and the max is 150ms. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 48: Phone Pattern

     Dial Tone – To configure the value of the local dial tone.  2 Dial Tone – To configure the value of the local 2 dial tone.  Flash Frequency – To configure the High and Low frequency for the Flash sending. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 49: Tone Setting

     Dial Tone – To configure the frequency, level gain and on/off time for the dial tone.  Ring Back Tone – To configure the frequency, level gain and on/off time for the dial tone. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 50: Support Functions

     Fast Start – Enable this function will support the Fast start function.  H.245 Tunneling – Enable or disable the Tunneling support.  H.245 after faststart – Enable or disable the H.245 after fast start function.  Early H.245 – Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 51: Phone Book

    2. It will be the insert function if user disable the Drop Prefix function and put the digits into the Insert Prefix table. 3. It will be the replace function if user enable the Drop Prefix function and put the digits into the Insert Prefix table. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 52  Add Data – Press this button if users fill the entire information table above.  Delete Date – If users want to delete the record from the table, enter the index number first and press this button. The record will be deleted. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 53: Prefix Configuration

    GK routed mode. All the numbers into this gateway will check out the prefix table first and find out the destination in the Routing Table. There is an example about the configuration, please follow up these steps. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 54 (see figure 3.14) Figure 3.14: Configure the Prefix Table The usage is as same as the drop, insert function of the Phone Book. Input (Prefix) Drop Insert Output Disable Disable 0200 Enable Enable Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 55 Release Mar., 2004 Press the Prefix Configuration button to reload the configuration table (see figure 3.15) Figure 3.15: Show the added table Please Commit it and Reboot the system if the configuration is finished. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 56: Routing Table

    FXS port without any define rules. The destination will be the IP side Fxo (Default) when the calls from the FXO port without any define rules. Figure 3.16: Routing Table Configuration Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 57: Change The Default Routing

    Please follow up the steps if you want to change the default routing: Pick up the side for the incoming calls and define the destination of this side. Press the Change Default to save the data. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 58 Figure 3.17: Change The Default Setting The default setting is changed after you press the Change Default button. Please press the Routing Table button again to show the new setting. Figure 3.18: The Default Setting Changed Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 59: Add A New Routing Table

    Please press the Routing Table button again to show the new setting. Figure 3.18: The Default Setting Changed Press Add Data button to save the configuration and press the Routing Table button again to reload the configuration. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 60 FXO and IP side. And the numbers you dial is between 1 and 10 digits. If this call matches the rule, it will be transferred to the FXO port whose E164 number is 1002. Please Commit it and Reboot the system if the configuration is finished. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 61: Fxo Password

    IP side or PSTN side if the password you type is correct. Please press the FXO Password button to configure the password (see figure 3.20) Figure 3.20: FXO Password Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 62: Ip Packet Tos

    TOS value. This WEB is for users to configure these values to make the packets with the correct values for the TOS service from the gateway. (see figure 3.21) Figure 3.21: TOS Configuration Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 63: Ddns Configuration

    DDNS Configuration button to configure it. (see figure 3.22) Figure 3.22: DDNS Configuration  Status – To enable or disable this function.  Server – Enter the server address of your DDNS server.  Host Name – Your DDNS address. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 64: Rtp Payload Type Configuration

     RFC2833 Payload Type – To define the payload type for RFC2833 type.  DTMF Payload Type – To define the payload for the DTMF type.  FAX Payload Type – To define the payload for the FAX type. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 65: Version And Information

     Boot Rom – The version of the Boot Rom layer.  Application Rom – The version of the Application Rom layer.  DSP Application – The version of the DSP Application Rom layer. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 66: Password

    The default setting for these two accounts are empty. Users could define the passwords for these two accounts. Please get more info from the following description. (see figure 3.25) Figure 3.25 Password  root – The password for the root account. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 67: Rom Upgrade

    FTP server. Please follow the step to update the gateway firmware version. (see figure 3.26) Figure 3.26 ROM Upgrade  TFTP/FTP server IP Address – Put the ip address of the TFTP or FTP Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 68 【Updating the firmware by the FTP server】 Pick up the “Rom Upgrade” button to enter the upgrading web page and switch to the FTP method. (see figure 3.27) Figure 3.27: ROM Upgrade for FTP Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 69 Executing the TFTP program before you want to use the TFTP upgrade method. Pick up the “Rom Upgrade” button to enter the upgrading web page and switch to the TFTP method. (see figure 3.29) Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 70 Key in the IP address of your TFTP server, pick up the file type for your upgrade file and the correct file name for upgrading. (see figure 3.30) Figure 3.30: TFTP information Press the OK button to start the upgrade procedure. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 71: Flash Clean

    Users could make all the configurations back to the default setting by this button. The password of the account and the networking configuration couldn’t be back to the default setting by this command. (see figure 3.31) Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 72: Commit

    Document Ver.: 2.2 Release Mar., 2004 Figure 3.31: Flash Clean 3.21 Commit This web page could save the configurations if users change some configurations. This is necessary for users change the configurations. (see figure 3.32) Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 73: Reboot System

    Release Mar., 2004 Figure 3.32: Commit 3.22 Reboot System This web page will restart the whole system. This is the necessary step for the changing the configurations and makes it executed. (see figure 3.33) Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 74: Command List

    FXSO H.323 Gateway User Manual Document Ver.: 2.2 Release Mar., 2004 Figure 3.33: Reboot System 4. Command List Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 75: Hyper Terminal Setting

    Execute the Hyper Terminal program, and then the following windows will pop-up on the screen. (START – Program files – Accessories – Communication – Hyper Terminal) Figure 4.1: Hyper Terminal Define a name such as ‘wg37’ for this new connection. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 76 Figure 4.2: Edit the name of the connection After pressing OK button, the next window appears, and then chooses COM1/2 Port, which you are going to use. Figure 4.3: Pick up the right interface to use Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 77 Configure the COM Port Properties as following:  Bits per second: 9600  Flow control: None Figure 4.4: Configure the right Bps and control Press ‘OK’ button, and then start to configure Gateway. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 78: Command List

    Record voice for greeting and ask pin code IP Packet ToS (Type of Service) values ddns Dynamic DNS update manipulation DSP payload type configuration and information ROM file update passwd Password setting information and configuration Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 79: Quit]

    Remove specified debug flag. -open Start to show debug messages. -close Stop showing debug messages. 4.2.4 [reboot] After commit command, type reboot to reload Gateway in new configuration. The procedure is as below: usr/config$ reboot Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 80: Flash]

    Warning: Only user who login with root can execute this command. Configurations of IP address and MAC address will be kept. 4.2.6 [commit] Save changes after configuring Gateway. ----------------------------------------------------------------------------------------------- usr/config$ commit Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 81: Ifaddr]

    PPPoE connection password. -reboot PPPoE connection password. Note: Range of ip address setting (0.0.0.0 ~ 255.255.255.255). SNTP mode (0=no update, 1=specify server IP, 2=broadcast mode). Example: ifaddr -ip 210.59.163.202 -mask 255.255.255.0 –gate 210.59.163.254 Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 82 WAN port of that IP sharing is using the dynamic IP address. This function has to be enabled. ----------------------------------------------------------------------------------------------- usr/config$ ifaddr -ipchange 1 This id is for the user name of the PPPoE usage. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 83: Time]

    64 bytes from 192.168.1.254: icmp_seq=3. time=0. ms ----192.168.1.254 PING Statistics---- 4 packets transmitted, 4 packets received, 0% packet loss round-trip (ms) min/avg/max = 0/1/5 usr/config$ 4.2.10 [sysconf] This command displays system information and configurations. --------------------------------------------------------------------------------------------- usr/config$ sysconf Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 84 FXO type.(Normal:0 / Force 2 dial:1) -rba Ring before answer.(For 1~10 ) Example: sysconf -ring 500 usr/config$ Parameters Usage: -print print out all current settings -idtime set the duration(in second) of two pressed digits in dial mode Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 85 “1” means gateway will generate ring back tone locally. -gwprefix drop or keep gateway prefix . “0” means when gateway has incoming call from IP side, it will not drop prefix before Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 86 In Taiwan the ring time of PSTN usually is 1000ms, so if user set ring time longer that 1000ms, FXO port may not be able to pick up the call from PSTN side. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 87: H323]

    -gkdis Gatekeeper discovery (On=1, Off=0). -gkid Gatekeeper ID. -rtp RTP port number (1024~65532). -ttl RAS TTL time (0~3600 second). -gkfind Gatekeeper finding port (1024~65535). -gkras Gatekeeper RAS port (1024~65535). Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 88 – device will register as H.323 defined Gateway, user has to define [prefix] in next command. Terminal type – device will register as H.323 defined Terminal, [prefix] command is not necessary. -dfgw default gateway is applied under Peer-to-Peer mode. User Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 89 IP address of GateKeeper is set as 255.255.255.255, LAN Phone will multicast to search a GateKeeper on network with configured GateKeeper name (please refer to -gkid); if IP address of GateKeeper is set, before LAN Phone register to Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 90: Line]

    Note: From –rtp to –conneto commands are for advanced users, please do not change the default settings if not necessary. 4.2.12 [line] This command is for configure each line parameters of Gateway. ---------------------------------------------------------------------------------------------- usr/config$ line Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 91 Note: This function can both work in GK or P2P mode. (1) Call out from FXS Line GK Mode Usage: Set gateway under gk mode. Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 92 Create phone book table with “pbook ” command. Create a Hotline table with “line ” command. ------------------------------------------------------------------------------- usr/config$ pbook –add name welltech ip 10.1.1.1 e164 1001 usr/config$ line –config 1 hotline 1001 ------------------------------------------------------------------------------- In this example means: if user picks up phone set of FXS Line1, gateway will automatically dial out IP address of “1001”.

  • Page 93: Route]

    -add [prefix number][dst number][e164 number] [min number][max number][hunt number] route -delete index route -modify index [prefix number][dst number][e164 number] [min number][max number][hunt number] route -ip [dst number][e164 number] route -fxs [dst number][e164 number] Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 94 IP side. (route –ip dst “destination port type” e164 “e.164 number of port”) -fxs create routing table for incoming call from FXS TELs. (route –fxs dst “destination port type” e164 “e.164 Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 95 4. route –fxo dst 2 This command means incoming call from FXO Lines will be routed to IP side. Note: (1) When destination is IP side, e.164 number doesn’t need to determine. (Ex. route –fxs dst 2) Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 96: Prefix]

    -modify modify a rule to drop or insert prefix digits of incoming call. (prefix –modify prefix “prefix number” drop 0/1 insert “insert number”) prefix set which prefix number to implement prefix rule. drop enable or disable drop function.If this function is enabled, Gateway Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 97: Pbook]

    : 1 ~ 10 digits. Example: pbook -add name test e164 1234 ip 192.168.1.10 port 1720 drop 1 insert 5678 pbook -delete 1 pbook -modify 1 name test e164 5678 ip 192.168.1.10 port 1720 drop 0 Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 98 IP Address. In other words, user dial this e164 number to reach destination, destination will receive the number and find out if it is matched to its e164, including Line number in some particular device. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 99: Voice]

    G.729B (20/40/60 ms) G.729AB (20/40/60 ms) -priority Priority preference of installed codecs. G.723 G.711A G.711U G.729 G.729A G.729B G.729AB -volume Specify the following levels: voice volume (0~63, default: 28), input gain (0~63, default: 28), Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 100 (1) For 3702A there are 2 version of Application rom, please check version of Application rom (rom –print). If the version is 2fxso729.102, 3702A doesn’t have codec G.723.1. If the version is sfxso723.102, 3702A doesn’t have codec G.729 series. Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 101: Support]

    Note: be sure to know well the application before you change voice parameters because this might cause incompatibility. 4.2.17 [support] This command provides some extra functions that might be needed by users. ----------------------------------------------------------------------------------------------- usr/config$ support Special Voice function support manipulation Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 102 Correction Mode ability. When high-speed T.38 FAX is running, Gateway will automatically execute ECM function. -t38asn1 Enable the ASN.1 support with the FAX. -faxrdd set fax redundancy depth. User can increase FAX redundancy depth when network traffic is heavy. For Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 103: Phone]

    Phone ringing , ringback tone , busy tone , dial tone setting and notes Usage: phone [-ring [freq ][ringON ][ringOFF ][ringLevel]] [-rbt [freqHi ][freqLo ][freqHiLev][freqLoLev] [Tone1ON][Tone1OFF][Tone2ON ][Tone2OFF ]] [-bt [freqHi ][freqLo ][freqHiLev][freqLoLev] [Tone1ON][Tone1OFF][Tone2ON ][Tone2OFF ]] [-dt [freqHi ][freqLo ][freqHiLev][freqLoLev] [Tone1ON][Tone1OFF][Tone2ON ][Tone2OFF ]] Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 104 (ring – ring tone, rbt – ring back tone, bt – busy tone, dt – dial tone, flash – flash ). This parameter should be accompanied with tone type. For example: Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 105: Tone]

    The played tone type, when hook off a phone set of workable Gateway. -flash set the detective flash range in ms, for example, 300-500 ms. 4.2.19 [tone] This command is basically for FXO ports. ----------------------------------------------------------------------------------------------- usr/config$ tone Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 106 (tone “index of tone” “frequency of high” “frequency of low” “level of high” “level of low” “on time of high” “off time of high” “on time of low” “off time of low” ) Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 107: Fxopwd]

    PSTN side to IP side, 2 means both sides. Once user enables FXO password function, caller will be asked to enter password when call in PSTN side or IP side according to the direction of password being implemented. (fxopwd –a Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 108: Record]

    –print. ----------------------------------------------------------------------------------------------- usr/config$ record -greeting test.100 Please off hook TEL 1 and press (N) for next step... Press (R) to start record... Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 109 User must assign a file name for askpin file, once record is finished, file recorded will be display in rom –print. ----------------------------------------------------------------------------------------------- usr/config$ record -askpin askpintest Please off hook TEL 1 and press (N) for next step... Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 110 Ask Pin : askpintest usr/config$ Note: Remember to press enter after press any command. -tone analyze tone frequency. Gateway can analyze tone frequency as user provide tone in FXO Line1. ----------------------------------------------------------------------------------------------- usr/config$ record -tone Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 111 A PSTN line which connect with the Line 1 port. A analog phone connect with the Tel 1 port. Configure Peer-to-Peer mode. Please record the disconnect tone just follow the stage as below ： Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 112 -tone Press (R) to start record... (Please make sure that you are already finish the steps 2 ~ 7) r (Press “Enter” button after you key in “R”) ................................................................ Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 113 Tone1 off : 35 Tone2 on : 1023 Tone2 off : 1023 Disconnect tone 3 paramter Frequency high : 620 frequency low : 480 frequency high level frequency low level Tone1 on : 50 Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 114 Analizing!! Please wait a moment... (You could hang up the call from PSTN if you get this message) Frequency 1 : 473 Frequency 2 (2623) is more than 1000, please ignore it. 0. 25sec on 0.25sec off Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 115 Tone1 on : 50 Tone1 off : 50 Tone2 on : 1023 Tone2 off : 1023 Disconnect tone 4 paramter Frequency high : 473 frequency low : 473 Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 116: Tos]

    Note: The value of rtptype and sigtype is from 0 to 63. It’s working if it supported by your network. 4.2.23 [ddns] The dynamic DNS service information and configuration ----------------------------------------------------------------------------------------------- Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 117 -enable enable the DDNS function -server enter the server address of thr DDNS server you use -hostname enter the domain name address which you get from the DDNS server key in your id Copyright (c) 2002 Welltech Computer Co. Ltd.

  • Page 118: Pt]

    -modembypass Configure the MODEM ByPass payload type -redundancy Configure the Redundancy payload type -modemrelay Configure the MODEM Relay payload type Example: pt -rfc2833 96 -fax 101 usr/config$ 4.2.25 [rom] ROM file information and firmware upgrade function. ----------------------------------------------------------------------------------------------- usr/config$ rom Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 119 -app, boot, boot2m, dsptest, dspcore, dspapp, greeting, askpin update main Application program code, Boot code, DSP testing code, DSP kernel code, DSP application code, greeting file, askpin file. to specify TFTP server’s IP address when upgrading ROM Copyright (c) 2002 Welltech Computer Co. Ltd.
  • Page 120 Note : “login name” can be “root” or “administrator” only. “root” and “administrator” have the same authorization, except some commands that can be executed by “root” only – “passwd –clean”, “rom –boot”, ”rom –bot2m” and “flash –clean”. Copyright (c) 2002 Welltech Computer Co. Ltd.
