Cradle Hook is
padded with soft
urethane to protect
your bike finish.
Angle & position
are adjustable.
Cradle height is
adjustable in 3
positions without
requiring any tool.
Setting up is very
easy! Just lean to
the wall.
(Pillar should be set
parallel to the wall)
!
GravityStand is designed to keep
enough stability. But we highly
recommend you to fix the stand
to the wall with the supplied strap
to prevent any
accident.
M3.5x15 or 25
Screw
GravityStand 2
Insert Plastic Bracket into
1
each Leg.
Insert Metal Plate into
2
Lower Pillar, put Plastic
Cover onto each Leg, then
put through Guide Pin into
either hole for temporally
assembling.
Be sure the square holes on
Lower Pillar must face to
front side.
Metal Plate
Screw M6x40 Bolt into the
3
hole without Guide Pin.
(You don't need to tighten
the bolts so much now.)
M6x40 Bolt
- Page 1 -
instructions manual
Plastic Bracket
Leg
Lower Pillar
Guide Pin
Plastic Cover
Leg
M6x40 Bolt
Remove Guide Pin.
4
Remove
Screw M6x40 Bolt to
5
another hole.
M6x40 Bolt
M6x40 Bolt
Tighten all M6x40 Bolts
6
firmly.
Install Metal Plate to the
7
top holes on Lower Pillar
with M6x12 Bolt.
M6x12 Bolt
Metal
Plate
