BIKE REPAIR STAND RS-X INSTRUCTION MANUAL

HOW TO SET-UP YOUR RS-X

Install the leg with supplied two screws and open the
1
frame. (see Fig. A)
!
Open the arm and hook one of the three bars which are
2
located between the main frame. You can choose your
favorite stand height by selecting one of the hooks.
(see Fig. B)
Thank you for purchasing the Minoura "RS-X"
bike repair stand.
The RS-X is a simple, elegant and stable stand
with a quick folding mechanism for easy storage
and transportation.
The frame is height adjustable in three levels and
the front fork support is fully adjustable to suit
various bike frame sizes and your favorite work-
ing position.
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MINOURA RS-X

  • Page 1 BIKE REPAIR STAND RS-X INSTRUCTION MANUAL Thank you for purchasing the Minoura “RS-X” bike repair stand. The RS-X is a simple, elegant and stable stand with a quick folding mechanism for easy storage and transportation. The frame is height adjustable in three levels and...
  • Page 2 Otherwise the arm may come loose if you lift up your bike from the stand. (see Fig. C) HOW TO MOUNT YOUR BIKE ON THE RS-X Loosen both side knob bolts to make the front fork mount loose. (see Fig. D) Insert the front fork end onto the fork mount, and tighten the fork securely with the quick release skewer.
