Preface

About this Manual

Thank you for purchasing and using the Intel
This manual is written for system technicians who are responsible for troubleshooting,
upgrading, and repairing this server board. This document provides a brief overview of
the features of the board/chassis, a list of accessories or other components you may need,
troubleshooting information, and instructions on how to add and replace components on
the Intel Server Board SE7230NH1-E User Guide. For the latest version of this manual,
refer to http://support.intel.com/support/motherboards/server/SE7230NH1-E/.

Manual Organization

Chapter 1 provides a brief overview of the Server Board SE7230NH1-E. In this chapter,
you will find a list of the server board features, drawings of the product, and product
diagrams to help you identify components and their locations.
Chapter 2 provides instructions on using the utilities that are shipped with the board or
that may be required to update the system. This includes how to navigate through the
BIOS Setup screens, how to perform a BIOS update, and how to reset CMOS. Information
about the specific BIOS settings and screens is available in the Technical Product
Specification. See
Product Specification.
Chapter 3 provides instructions on adding and replacing components. Use this chapter for
step-by-step instructions and diagrams for installing or replacing components such as the
memory, processor, control panel board, and the battery, among other components.
Chapter 4 provides troubleshooting information. In this chapter, you will find BIOS error
messages and POST code messages. You will also find suggestions for performing
troubleshooting activities to identify the source of a problem.
Intel® Server Board SE7230NH1-E and Intel® Server Platform SR1475NH1-E User's Guide
"Additional Information and Software"
®
Server Board SE7230NH1-E.
for a link to the Technical
iii
