Figure 7. Removing Protective Processor Cover; Figure 8. Installing The Processor; Figure 9. Removing The Socket Protective Cover - Intel SR1475NH1 - Server Platform - 0 MB RAM User Manual

7. Take the processor out of the box and remove the protective shipping cover (see
Figure
8. Orient the processor with the socket so that the processor cutout matches the socket
notch (see letter "A" in
"B" in
9. Grasp the socket protective cover tab and pull away from the load plate (see letter "A"
in Figure
"B" in
®
Intel Server Board SE7230NH1-E and Intel
7).

Figure 7. Removing Protective Processor Cover

Figure
Figure 8).
A

Figure 8. Installing the Processor

9). Remove the socket protective cover and store for future use (see letter
Figure 9).

Figure 9. Removing the Socket Protective Cover

®
Server Platform SR1475NH1-E User's Guide
TP01789
8), and insert the processor into the socket (see letter
B
A
B
TP01788
TP01790
