5. Install the 55-mm spacer bracket to each front rack column by aligning the
6. Slide the tray on top of the mounting rails to the back of the rack
7. Tighten the pre-installed T-20 screws on each side of the tray front to
Figure 6
8. Using two people or an appropriately rated lift, install the autoloader onto
Chapter 1
top of the bracket with the top clip nut and tightening the two pre-installed
Phillips screws (see Figure
(see Figure 6).
secure the tray to the installed spacer brackets on the rack. You might need
to support the tray while you are tightening the screws.
Installing the Tray
the right side of the tray, gently sliding it toward the back of the rack.
Ensure that the front edge of the autoloader is still accessible for the next
step.
6).
Installing the Autoloader into a Rack 25
