Back Panel Controls

IN FROM ANT Use to connect an off-air antenna or cable TV signal to the
®
DSS system.
OUT TO TV Use to connect the DSS
TV has audio/video jacks, you should use those jacks to get better picture
and sound quality.
D-VHS Use to connect the DSS
a digital audio/video (DAV) cable.
S-VIDEO Provides the best picture quality. If your TV has S-VIDEO
capability, use this jack along with the audio/video jacks to connect the
DSS ® receiver to your TV.
VIDEO Provides better picture quality than the OUT TO TV jack. If your TV
has audio/video capability, use this jack to connect the DSS
TV. You must also connect the AUDIO jacks.
AUDIO (R and L) Provide better sound quality than the OUT TO TV jack. If
your TV has audio/video capability, use these jacks to connect the DSS
receiver to your TV. You must also connect the VIDEO jack.
AUX RF ANT IN Use to connect an optional RF antenna for RF remote
signals. Connecting an antenna extends the remote's range.
WIDE BAND DATA PORT This port allows you to connect the DSS
to future services and accessories. A shielded cable and additional hardware
may be required.
LOW SPEED DATA PORT this port allows you to connect the DSS
to accessories, such as the Home Control base module.
SATELLITE IN Use to connect the DSS
PHONE JACK Use to connect a phone line to the DSS
system requires a phone line connection to periodically call out to program
providers.
VCR CONTROL Allows the receiver to control your VCR.
REMOTE IN Use in conjunction with a remote control signal sender.
AUX RF ANT IN
VCR CONTROL
R AUDIO L WIDE BAND DATA
REMOTE IN
®
receiver to your TV. However, if your
® receiver to a compatible D-VHS VCR with
®
receiver to the satellite dish antenna.
®
SATELLITE IN
®
receiver to your
®
® system
® system
receiver. The DSS ®
PHONE JACK
LOW SPEED DATA
