First Things First
Connecting a Compatible
D-VHS VCR
®
The DSS receiver can send a digital signal to a compatible D-VHS
VCR. The D-VHS VCR can then record and playback recordings
through the DSS ® receiver. If you have a D-VHS VCR you must
connect both devices so they can send and receive digital signals.
1) Connect a digital audio/video (DAV) cable as shown.
2) Connect RCA type audio/video cables as shown.
The D-VHS VCR and DSS
cable. It is not necessary to connect the VCR controller or enter the
VCR type described earlier in this section.

Interactive Setup

If you self-installed your satellite dish antenna, you may have already
used the interactive setup to find the dish pointing coordinates, acquire
and fine-tune the signal, and run a system test.
If you need to run the interactive setup again, select Options from the
Main menu, then select Interactive Setup .
If you just want to check your dish pointing coordinates, or run the
signal strength meter, select Dish Pointing from the Main menu.
Ordering DSS
After you have installed your system, you should contact the service
providers, DIRECTV and USSB to receive DSS
Programming with DIRECTV:
Programming with USSB:
18
® receiver communicate through the DAV
®
Programming
® programming.
Call 1-800-347-3288
Call 1-800-204-USSB
DSS
IN FROM ANT
RECEIVER
D-VHS
S-VIDEO
OUT TO TV
D-VHS
IN FROM ANT
D-VHS
VIDEO IN
CH3
VCR
CH4
OUT TO TV
VIDEO OUT
When you order programming, you
need to know your Access Card number.
To get the number, select Options from
the Main menu, then System Options ,
and then select System Test.
Wait for the system to run all of it's
tests. The Access Card number is
displayed at the end of the system test.
Write the Access Card number in the
space below for easy reference:
________________________________
VIDEO R L
AUDIO
SATELLITE IN
VIDEO R L
AUDIO
AUDIO IN
R L
AUDIO OUT
